STR-DN1050
26
SECTION 6
DIAGRAMS
• Circuit Boards Location
STANDBY board
DCDC board
DIGITAL board
NETWORK board
TUNER1 board
MAIN board
NFC ICON PC board
RC-S801/A5 (WW)
POWER KEY board
GND BRACKET board
HEADPHONE board
FRONT JACK board
DISPLAY board
BLUETOOTH module
HDMI FRONT IN board
