96
STR-DN1050
SECTION 8
ELECTRICAL PARTS LIST
A-1989-174-A DCDC BOARD, COMPLETE
*********************
< CAPACITOR >
C901 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C902 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C903 1-126-946-11 ELECT 6800uF 20% 25V
C904 1-126-942-61 ELECT 1000uF 20% 25V
C907 1-100-756-91 CERAMIC CHIP 0.047uF 10% 50V
C908 1-100-756-91 CERAMIC CHIP 0.047uF 10% 50V
C1901 1-104-665-11 ELECT 100uF 20% 25V
C1902 1-116-865-11 CERAMIC CHIP 10uF 10% 25V
C1903 1-116-865-11 CERAMIC CHIP 10uF 10% 25V
C1904 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C1905 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C1907 1-112-775-11 CERAMIC CHIP 0.0022uF 10% 50V
C1908 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C1909 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C1910 1-100-905-11 CERAMIC CHIP 0.001uF 10% 50V
C1911 1-104-658-91 ELECT 100uF 20% 10V
C1912 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
C1913 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
C1914 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C1921 1-104-665-11 ELECT 100uF 20% 25V
C1922 1-116-865-11 CERAMIC CHIP 10uF 10% 25V
C1923 1-116-865-11 CERAMIC CHIP 10uF 10% 25V
C1924 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C1925 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C1927 1-112-775-11 CERAMIC CHIP 0.0022uF 10% 50V
C1928 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C1929 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C1930 1-100-905-11 CERAMIC CHIP 0.001uF 10% 50V
C1931 1-104-658-91 ELECT 100uF 20% 10V
C1932 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
C1933 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
C1934 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C1941 1-104-665-11 ELECT 100uF 20% 25V
C1942 1-116-865-11 CERAMIC CHIP 10uF 10% 25V
C1943 1-116-865-11 CERAMIC CHIP 10uF 10% 25V
C1944 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C1945 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C1947 1-112-777-11 CERAMIC CHIP 0.01uF 10% 25V
C1948 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C1949 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C1950 1-100-905-11 CERAMIC CHIP 0.001uF 10% 50V
C1951 1-104-658-91 ELECT 100uF 20% 10V
C1952 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
C1953 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
C1954 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C1955 1-104-658-91 ELECT 100uF 20% 10V
C1956 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
C1957 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
C1958 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C1959 1-100-905-11 CERAMIC CHIP 0.001uF 10% 50V
C1960 1-104-665-11 ELECT 100uF 20% 25V
C1961 1-116-865-11 CERAMIC CHIP 10uF 10% 25V
C1962 1-116-865-11 CERAMIC CHIP 10uF 10% 25V
C1963 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C1964 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C1966 1-112-777-11 CERAMIC CHIP 0.01uF 10% 25V
C1967 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C1968 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C1969 1-100-905-11 CERAMIC CHIP 0.001uF 10% 50V
C1970 1-104-658-91 ELECT 100uF 20% 10V
C1971 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
C1972 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
C1973 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C1978 1-116-865-11 CERAMIC CHIP 10uF 10% 25V
C1979 1-116-865-11 CERAMIC CHIP 10uF 10% 25V
C1980 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C1981 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C1983 1-112-775-11 CERAMIC CHIP 0.0022uF 10% 50V
C1984 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C1985 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C1986 1-100-905-11 CERAMIC CHIP 0.001uF 10% 50V
C1987 1-104-658-91 ELECT 100uF 20% 10V
C1988 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
C1989 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
C1990 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C1991 1-104-665-11 ELECT 100uF 20% 25V
C1992 1-116-865-11 CERAMIC CHIP 10uF 10% 25V
C1993 1-116-865-11 CERAMIC CHIP 10uF 10% 25V
C1994 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C1995 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
AUS : Australian model
CND : Canadian model
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Les composants identifi és par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce por-
tant le numéro spécifi é.
Les composants identifi és par la marque
9 contiennent des informations confi den-
tielles.
Suivre scrupuleusement les instructions
chaque fois qu’un composant est remplacé
et / ou réparé.
The components identifi ed by mark 9 con-
tain confi dential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
DCDC
To Next Page
