Sony STR-DN1050 - Page 109

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DN1050
109
R3726 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3727 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R3728 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R3730 1-218-990-81 SHORT CHIP 0
R3731 1-218-990-81 SHORT CHIP 0
R4180 1-208-931-11 METAL CHIP 68K 0.5% 1/16W
R4181 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R4182 1-208-709-11 METAL CHIP 12K 0.5% 1/16W
R4183 1-208-939-11 METAL CHIP 150K 0.5% 1/16W
R4184 1-218-953-11 METAL CHIP 1K 5% 1/16W
R4185 1-218-977-11 METAL CHIP 100K 5% 1/16W
R4186 1-218-965-11 METAL CHIP 10K 5% 1/16W
R4187 1-208-953-11 METAL CHIP 560K 0.5% 1/16W
R4188 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R4189 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R4190 1-218-965-11 METAL CHIP 10K 5% 1/16W
R4191 1-218-990-81 SHORT CHIP 0
R4193 1-218-965-11 METAL CHIP 10K 5% 1/16W
R4195 1-216-295-91 SHORT CHIP 0
R7004 1-218-941-81 METAL CHIP 100 5% 1/16W
R7006 1-216-295-91 SHORT CHIP 0
R7007 1-216-295-91 SHORT CHIP 0
R7011 1-218-990-81 SHORT CHIP 0
R7012 1-218-990-81 SHORT CHIP 0
R7013 1-218-965-11 METAL CHIP 10K 5% 1/16W
R7014 1-218-965-11 METAL CHIP 10K 5% 1/16W
R7015 1-218-965-11 METAL CHIP 10K 5% 1/16W
R7016 1-218-965-11 METAL CHIP 10K 5% 1/16W
R7017 1-218-965-11 METAL CHIP 10K 5% 1/16W
R7018 1-218-965-11 METAL CHIP 10K 5% 1/16W
R7022 1-218-937-11 METAL CHIP 47 5% 1/16W
R7024 1-218-937-11 METAL CHIP 47 5% 1/16W
R7025 1-218-937-11 METAL CHIP 47 5% 1/16W
R7026 1-218-937-11 METAL CHIP 47 5% 1/16W
R7029 1-218-941-81 METAL CHIP 100 5% 1/16W
R7031 1-218-941-81 METAL CHIP 100 5% 1/16W
R7032 1-218-990-81 SHORT CHIP 0
R7033 1-218-937-11 METAL CHIP 47 5% 1/16W
R7034 1-218-937-11 METAL CHIP 47 5% 1/16W
R7035 1-218-937-11 METAL CHIP 47 5% 1/16W
R7037 1-218-965-11 METAL CHIP 10K 5% 1/16W
R7038 1-218-965-11 METAL CHIP 10K 5% 1/16W
R7041 1-218-965-11 METAL CHIP 10K 5% 1/16W
R7043 1-218-947-11 METAL CHIP 330 5% 1/16W
R7044 1-218-937-11 METAL CHIP 47 5% 1/16W
R7049 1-208-711-11 METAL CHIP 15K 0.5% 1/16W
R7050 1-208-908-11 METAL CHIP 7.5K 0.5% 1/16W
R7051 1-208-871-81 METAL CHIP 220 0.5% 1/16W
R7054 1-216-295-91 SHORT CHIP 0
R7055 1-216-295-91 SHORT CHIP 0
R7061 1-218-965-11 METAL CHIP 10K 5% 1/16W
R7064 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R7066 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R7067 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R7068 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R7069 1-218-941-81 METAL CHIP 100 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB2101 1-234-372-11 RES, NETWORK 100 (1005X4)
RB2102 1-234-372-11 RES, NETWORK 100 (1005X4)
RB2106 1-234-372-11 RES, NETWORK 100 (1005X4)
RB2107 1-234-372-11 RES, NETWORK 100 (1005X4)
RB2108 1-234-372-11 RES, NETWORK 100 (1005X4)
RB2109 1-234-376-11 RES, NETWORK 2.2K (1005X4)
RB2110 1-234-372-11 RES, NETWORK 100 (1005X4)
RB2500 1-200-051-21 RES, NETWORK 150 (1005X4)
RB2501 1-200-051-21 RES, NETWORK 150 (1005X4)
RB2502 1-200-051-21 RES, NETWORK 150 (1005X4)
RB2503 1-200-051-21 RES, NETWORK 150 (1005X4)
RB3001 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB3002 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB3003 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB3004 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB3005 1-234-372-11 RES, NETWORK 100 (1005X4)
RB3006 1-234-372-11 RES, NETWORK 100 (1005X4)
RB3200 1-234-371-11 RES, NETWORK 47 (1005X4)
RB3201 1-234-371-11 RES, NETWORK 47 (1005X4)
RB3202 1-234-371-11 RES, NETWORK 47 (1005X4)
RB3203 1-234-371-11 RES, NETWORK 47 (1005X4)
RB3206 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB3207 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
< RELAY >
RY3201 1-755-695-11 RELAY
< VIBRATOR >
X2100 1-781-646-21 VIBRATOR, CERAMIC (4MHz)
X2102 1-814-344-11 QUARTZ CRYSTAL UNIT (24.576MHz)
X2500 1-814-242-11 VIBRATOR, CRYSTAL (25MHz)
X3000 1-781-646-21 VIBRATOR, CERAMIC (4MHz)
X3200 1-814-628-11 QUARTZ CRYSTAL UNITS (28.63636MHz)
X3501 1-814-754-11 QUARTZ CRYSTAL UNIT (27MHz)
*************************************************************
A-1989-182-A DISPLAY BOARD, COMPLETE
***********************
< CAPACITOR >
* C114 1-116-723-11 CERAMIC CHIP 4.7uF 10% 10V
C115 1-118-291-11 CERAMIC CHIP 100PF 5% 50V
C116 1-115-871-11 ELECT 1uF 20% 50V
C117 1-126-795-11 ELECT 10uF 20% 50V
C118 1-126-514-11 ELECT 22uF 20% 16V
C119 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C120 1-126-514-11 ELECT 22uF 20% 16V
C121 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C122 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C123 1-115-871-11 ELECT 1uF 20% 50V
C124 1-126-382-11 ELECT 100uF 20% 16V
C125 1-162-966-91 CERAMIC CHIP 0.0022uF 10% 50V
C126 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C127 1-119-943-91 ELECT 47uF 20% 50V
C128 1-116-405-11 CERAMIC CHIP 0.01uF 10% 100V
C129 1-162-968-91 CERAMIC CHIP 0.0047uF 10% 50V
C130 1-114-324-11 CERAMIC CHIP 0.022uF 10% 50V
C131 1-124-635-00 ELECT 220uF 20% 6.3V
C132 1-114-811-11 CERAMIC CHIP 0.0033uF 10% 50V
C133 1-114-811-11 CERAMIC CHIP 0.0033uF 10% 50V
C134 1-114-811-11 CERAMIC CHIP 0.0033uF 10% 50V
C135 1-114-811-11 CERAMIC CHIP 0.0033uF 10% 50V
DIGITAL DISPLAY
