Sony STR-DN1050 - Page 111

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DN1050
111
R114 1-216-839-11 METAL CHIP 33K 5% 1/10W
R115 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R116 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R117 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R118 1-216-841-11 METAL CHIP 47K 5% 1/10W
R119 1-216-841-11 METAL CHIP 47K 5% 1/10W
R120 1-216-296-11 SHORT CHIP 0
R121 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R122 1-216-821-11 METAL CHIP 1K 5% 1/10W
R123 1-216-833-11 METAL CHIP 10K 5% 1/10W
R124 1-216-841-11 METAL CHIP 47K 5% 1/10W
R125 1-218-866-11 METAL CHIP 6.2K 0.5% 1/10W
R126 1-216-842-11 METAL CHIP 56K 5% 1/10W
R127 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R128 1-216-821-11 METAL CHIP 1K 5% 1/10W
R129 1-216-845-11 METAL CHIP 100K 5% 1/10W
R130 1-250-616-11 METAL CHIP 1K 1% 1/10W
R131 1-250-624-11 METAL CHIP 2.2K 1% 1/10W
R132 1-250-632-11 METAL CHIP 4.7K 1% 1/10W
R133 1-250-624-11 METAL CHIP 2.2K 1% 1/10W
R134 1-250-624-11 METAL CHIP 2.2K 1% 1/10W
R135 1-250-616-11 METAL CHIP 1K 1% 1/10W
R136 1-250-592-11 METAL CHIP 100 1% 1/10W
R137 1-250-592-11 METAL CHIP 100 1% 1/10W
R138 1-250-652-11 METAL CHIP 33K 1% 1/10W
R139 1-249-428-11 CARBON 8.2K 5% 1/4W
R140 1-250-612-11 METAL CHIP 680 1% 1/10W
R141 1-257-172-91 METAL CHIP 100 5% 1/3W
R142 1-250-640-11 METAL CHIP 10K 1% 1/10W
R143 1-250-600-11 METAL CHIP 220 1% 1/10W
R144 1-250-664-11 METAL CHIP 100K 1% 1/10W
R145 1-250-640-11 METAL CHIP 10K 1% 1/10W
R146 1-250-648-11 METAL CHIP 22K 1% 1/10W
R147 1-250-640-11 METAL CHIP 10K 1% 1/10W
R148 1-250-648-11 METAL CHIP 22K 1% 1/10W
R149 1-250-612-11 METAL CHIP 680 1% 1/10W
R150 1-250-608-11 METAL CHIP 470 1% 1/10W
R151 1-249-428-11 CARBON 8.2K 5% 1/4W
R154 1-216-809-11 METAL CHIP 100 5% 1/10W
R156 1-250-664-11 METAL CHIP 100K 1% 1/10W
R158 1-216-809-11 METAL CHIP 100 5% 1/10W
R159 1-216-809-11 METAL CHIP 100 5% 1/10W
R160 1-216-809-11 METAL CHIP 100 5% 1/10W
R161 1-216-809-11 METAL CHIP 100 5% 1/10W
R164 1-216-864-11 SHORT CHIP 0
R166 1-216-864-11 SHORT CHIP 0
R172 1-216-864-11 SHORT CHIP 0
< SWITCH >
S101 1-762-875-21 SWITCH, TACTILE (PURE DIRECT)
S102 1-762-875-21 SWITCH, TACTILE (DIMMER)
S103 1-762-875-21 SWITCH, TACTILE (ZONE POWER)
S104 1-762-875-21 SWITCH, TACTILE (ZONE CONTROL)
S105 1-762-875-21 SWITCH, TACTILE (DISPLAY)
S108 1-762-875-21 SWITCH, TACTILE (A.F.D./2CH)
S109 1-762-875-21 SWITCH, TACTILE (MOVIE)
S110 1-762-875-21 SWITCH, TACTILE (MUSIC)
< TRANSFORMER >
T100 1-443-645-11 TRANSFORMER, DC CONVERTER
*************************************************************
A-1989-184-A FRONT JACK BOARD, COMPLETE
***************************
< CAPACITOR >
C150 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C151 1-126-176-11 ELECT 220uF 20% 10V
C152 1-114-325-11 CERAMIC CHIP 0.1uF 10% 25V
C154 1-116-743-11 CERAMIC CHIP 0.22uF 10% 16V
< CONNECTOR >
CN104 1-564-721-11 PIN, CONNECTOR (SMALL TYPE) 5P
CN106 1-819-866-11 USB CONNECTOR (A) (
DC5V 1A MAX)
< DIODE >
D126 6-502-968-01 DI DZ2J062M0L
D129 6-500-400-01 DIODE BAV99-215
D130 6-500-400-01 DIODE BAV99-215
< JACK >
J100 1-822-453-11 SMALL TYPE JACK (3.5MM) (AUTO CAL MIC)
< JUMPER RESISTOR >
JR200 1-216-296-11 SHORT CHIP 0
JR201 1-216-296-11 SHORT CHIP 0
< RESISTOR >
R190 1-216-864-11 SHORT CHIP 0
R191 1-216-864-11 SHORT CHIP 0
R192 1-216-864-11 SHORT CHIP 0
R193 1-216-809-11 METAL CHIP 100 5% 1/10W
*************************************************************
A-1989-192-A HDMI FRONT IN BOARD, COMPLETE
*****************************
< CAPACITOR >
* C3801 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C3802 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C3803 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C3806 1-118-036-11 CERAMIC CHIP 0.1uF 10% 50V
C3807 1-118-036-11 CERAMIC CHIP 0.1uF 10% 50V
< CONNECTOR >
* CN3800 1-842-685-11 HDMI CONNECTOR
CN3802 1-580-756-21 PIN, CONNECTOR (SMD) 7P
CN3808 1-843-670-11 HDMI CONNECTOR
((VIDEO 2 IN) HDMI MHL DC5V 1A MAX)
< EARTH TERMINAL >
* ET3801 1-780-408-11 TERMINAL, LUG
< FERRITE BEAD >
FB3800 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3801 1-460-516-21 INDUCTOR, FERRITE BEADS (1005)
FB3802 1-482-231-11 INDUCTOR, FERRITE BEAD
< IC >
IC3800 6-721-119-01 IC TCA9517DGKR
DISPLAY FRONT JACK HDMI FRONT IN
