STR-DN1050
85
Pin No. Pin Name I/O Description
R22 TX2_1+ O TMDS data (positive) output to the HDMI OUT B connector
R23 TX2_1– O TMDS data (negative) output to the HDMI OUT B connector
T1, T2 P[14], P[15] I Digital video signal input from the video A/D converter
T3, T4 GND - Ground terminal
T7 to T17 GND - Ground terminal
T20 HPD_TX2 I Hot plug detection signal input from the HDMI OUT B connector
T21 GND - Ground terminal
T22 TX2_0+ O TMDS data (positive) output to the HDMI OUT B connector
T23 TX2_0– O TMDS data (negative) output to the HDMI OUT B connector
U1, U2 P[10], P[11] I Digital video signal input from the video A/D converter
U3, U4 P[12], P[13] I Digital video signal input terminal Not used
U7, U8 GND - Ground terminal
U9 DVDD - Power supply terminal (+1.8V)
U10, U11 GND - Ground terminal
U12 DVDD - Power supply terminal (+1.8V)
U13, U14 GND - Ground terminal
U15 DVDD - Power supply terminal (+1.8V)
U16, U17 GND - Ground terminal
U20 R_TX2 - External resistor connection terminal
U21 GND - Ground terminal
U22 TX2_C+ O TMDS clock (positive) signal output to the HDMI OUT B connector
U23 TX2_C– O TMDS clock (negative) signal output to the HDMI OUT B connector
V1 to V4 P[6] to P[9] I Digital video signal input from the video A/D converter
V20 GND - Ground terminal
V21 PVDD4 - Power supply terminal (+1.8V)
V22 HEAC_2+ I HEAC (positive) signal input terminal Not used
V23 HEAC_2– I HEAC (negative) signal input terminal Not used
W1 to W4 P[2] to P[5] I Digital video signal input from the video A/D converter
W20 TEST3 - Test terminal
W21 PVDD6 - Power supply terminal (+1.8V)
W22 AVDD3 - Power supply terminal (+1.8V)
W23 NC - Not used
Y1, Y2 P[0], P[1] I Digital video signal input terminal Not used
Y3 DDR_DQS[2] O Data strobe signal output to the SD-RAM
Y4 GND - Ground terminal
Y5 DDR_DQ[23] I/O Two-way data bus with the SD-RAM
Y6 DVDD_DDR - Power supply terminal (+1.8V)
Y7 DDR_DQS[3] O Data strobe signal output to the SD-RAM
Y8 GND - Ground terminal
Y9 DDR_A[11] O Address signal output to the SD-RAM
Y10 DVDD_DDR - Power supply terminal (+1.8V)
Y11 DDR_A[4] O Address signal output to the SD-RAM
Y12 GND - Ground terminal
Y13 DDR_/CAS O Column address strobe signal output to the SD-RAM
Y14 DVDD_DDR - Power supply terminal (+1.8V)
Y15 DDR_/CK O Clock signal output to the SD-RAM
Y16 GND - Ground terminal
Y17 DDR_DQ[9] I/O Two-way data bus with the SD-RAM
Y18 DVDD_DDR - Power supply terminal (+1.8V)
Y19 DDR_DQ[14] I/O Two-way data bus with the SD-RAM
Y20 GND - Ground terminal
Y21 DDR_DQ[6] I/O Two-way data bus with the SD-RAM
Y22 PVDD_DDR - Power supply terminal (+1.8V)
Y23 GND - Ground terminal
AA1 DDR_DQ[18] I/O Two-way data bus with the SD-RAM
AA2, AA3 GND - Ground terminal
