Sony STR-DN1060 - MB-1409 Board (DN860)

STR-DN860/DN1060
13
2-6. MB-1409 BOARD (DN860)
5 CN501 (5P)
6 CN301 (11P)
E
F
G
E
H
I
F
G
0 one screw
(+BVTP 3 u 8)
qa one screw
(+BVTP 3 u 8)
qa two screws
(+BVTP 3 u 8)
qs clamp
qs clamp
qa three screws
(+BVTP 3 u 8)
qd bracket, HDMI
(N86)
qf four screws
(+BVTP 3 u 8)
qh heat sink (HDMI-B)
qj sheet, radiation
qk MB-1409 board
qg heat sink (HDMI-A)
H
I
1 wire (flat type)
(27 core) (CN3004)
4 wire (flat type)
(19 core) (CN8001)
3 CN8000 (13P)
2 wire (flat type)
(22 core) (CN8002)
7 six screws
(+B 3 u 5)
8 one screw
(+BVTP 3 u 8)
9 two screws
(+BVTP 3 u 8)
MB-1409 board
pin, lead
pin, lead
DISPLAY board
MB-1409 board
pin, lead and cable tie
:LUHVHWWLQJ
:LUHVHWWLQJ
Note: Process so that lead wire does
not contact CN502
rear side
