Sony STR-DN1060 - Front Panel Section

STR-DN860/DN1060
15
2-8. FRONT PANEL SECTION
SUPPORT boardpin, lead
MAIN board
DISPLAY board
FRONT HDMI board
MB-1409 board
pin, lead
cable tiecushion (R)
:LUHVHWWLQJ
:LUHVHWWLQJ
:LUHVHWWLQJ
2 Wire is removed
from the pin, lead.
3 cushion (R)
4 CN1391
(4P)
7 front panel
section
5 five screws
(+BVTP 3 u 8)
6 one screw
(+BVTP 3 u 8)
6 one screw
(+BVTP 3 u 8)
5 two screws
(+BVTP 3 u 8)
rear side
rear side
1 Cut the
cable tie
1 Cut the
cable tie
(DN1060)
(DN1060)
(DN1060)
(DN1060)
(DN1060)
(DN1060)
(DN1060)
(DN1060)
(DN1060)
(DN860)
MAIN board
POWERKEY
board
pin, lead
rear side
