STR-DN860/DN1060
2
HDMI Video
Input/Output (HDMI Repeater block)
STR-DN1060: HDMI IN SAT/CATV (MHL) and HDMI OUT A (TV) jacks support HDCP 2.2 protocol.
STR-DN860: HDMI IN SAT/CATV (MHL) and HDMI TV OUT jacks support HDCP 2.2 protocol.
HDCP 2.2 is newly enhanced copyright protection technology that is used to protect content such as 4K movies.
Format 2D
3D
Frame
packing
Side-by-Side
(Half)
Over-Under
(Top-and-Bottom)
4096 × 2160p @ 59.94/60 Hz
a
1)
–– –
4096 × 2160p @ 50 Hz
a
1)
–– –
3840 × 2160p @ 59.94/60 Hz
a
1)
–– –
3840 × 2160p @ 50 Hz
a
1)
–– –
4096 × 2160p @ 23.98/24 Hz
a
2)4)
–– –
3840 × 2160p @ 29.97/30 Hz
a
2)4)
–– –
3840 × 2160p @ 25 Hz
a
2)4)
–– –
3840 × 2160p @ 23.98/24 Hz
a
2)4)
–– –
1920 × 1080p @ 59.94/60 Hz
a
4)
–
a
4)
a
4)
1920 × 1080p @ 50 Hz
a
4)
–
a
4)
a
4)
1920 × 1080p @ 29.97/30 Hz
a
3)
a
4)
a
3)
a
3)
1920 × 1080p @ 25 Hz
a
3)
a
4)
a
3)
a
3)
1920 × 1080p @ 23.98/24 Hz
a
3)
a
4)
a
3)
a
3)
1920 × 1080i @ 59.94/60 Hz
a
3)
aa
3)
a
3)
1920 × 1080i @ 50 Hz
a
3)
aa
3)
a
3)
1280 × 720p @ 59.94/60 Hz
a
3)
a
4)
a
3)
a
3)
1280 × 720p @ 50 Hz
a
3)
a
4)
a
3)
a
3)
1280 × 720p @ 29.97/30 Hz
a
3)
a
4)
a
3)
a
3)
1280 × 720p @ 23.98/24 Hz
a
3)
a
4)
a
3)
a
3)
720 × 480p @ 59.94/60 Hz
a
3)
–– –
720 × 576p @ 50 Hz
a
3)
–– –
640 × 480p @ 59.94/60 Hz
a
3)
–– –
1)
Supports YUV 4:2:0 / 8 bit format only.
2)
Supports 8 bit format only.
3)
These formats are also supported by MHL 2 and MHL 3
connection.
4)
These formats are also supported by an MHL 3 connection.
MHL section
Supported MHL version
Incorporates MHL 2 (front)*, MHL 3 (rear)
Maximum current
900 mA
* STR-DN1060 only.
iPhone/iPad/iPod section
DC 5V 1.0 A MAX
USB works with iPhone 6, iPhone 6 Plus, iPhone 5s, iPhone 5c,
iPhone 5, iPhone 4s, iPhone 4, iPhone 3GS, iPhone 3G, iPod
touch (2nd through 5th generation), iPod classic, and iPod nano
(3rd through 7th generation).
BLUETOOTH technology works with iPhone 6, iPhone 6 Plus,
iPhone 5s, iPhone 5c, iPhone 5, iPhone 4s, iPhone 4, iPhone
3GS, and iPod touch (4th and 5th generation).
AirPlay works with iPhone, iPad, and iPod touch with iOS 4.3.3
or later, Mac with OS X Mountain Lion or later, and PC with
iTunes 10.2.2 or later.
You can use “SongPal” app with this receiver via BLUETOOTH
or network connection.
You can only charge the iPhone/iPod when they are connected to
the USB port while the receiver is turned on.
USB section
(USB) port:
Type A (For connecting USB memory)
NETWORK section
Ethernet LAN
100BASE-TX
Wireless LAN
Compatible standards:
IEEE 802.11 a/b/g/n
Security:
WPA/WPA2-PSK, WEP
Radio frequency:
2.4 GHz, 5 GHz
BLUETOOTH section
Communication system
BLUETOOTH Specifi cation version 3.0
Output
BLUETOOTH Specifi cation Power
Class 1
Maximum communication range
Line of sight approx. 30 m (98.4 feet)
1)
Frequency band
2.4 GHz band (2.4000 GHz – 2.4835 GHz)
Modulation method
FHSS (Freq Hopping Spread Spectrum)
Compatible BLUETOOTH profi les
2)
A2DP 1.2 (Advanced Audio Distribution Profi le)
AVRCP 1.5 (Audio Video Remote Control Profi le)
SPP (Serial Port Profi le)
Supported Codecs
3)
SBC
4)
, AAC, LDAC
Transmission range (A2DP)
20 Hz – 20,000 Hz (Sampling frequency 44.1 kHz, 48 Hz,
88.2 kHz, 96 kHz)
1)
The actual range will vary depending on factors such as
obstacles between devices, magnetic fi elds around a microwave
oven, static electricity, cordless phone, reception sensitivity,
antenna’s performance, operating system, software application,
etc.
2)
BLUETOOTH standard profi les indicate the purpose of BLUE-
TOOTH communication between devices.
3)
Codec: Audio signal compression and conversion format
4)
Subband Codec
General
Power requirements
Area Power requirements
US, Canadian,
Taiwan
120 V AC, 60 Hz
Australian 230 V AC, 50 Hz
AEP, UK 230 V AC, 50/60 Hz
Power consumption
240 W
Power consumption (during standby mode)
STR-DN1060:
0.3 W (When [Control for HDMI], [Standby Through],
[Remote Start], [Bluetooth Standby] and all zone power
are set to [Off].)
0.8 W (When [Control for HDMI] is set to [On],
and [Standby Through], [Remote Start], [Bluetooth
Standby] and all zone power are set to [Off].)
1.7 W (When [Control for HDMI] and [Bluetooth
Standby] are set to [On], and [Standby Through],
[Remote Start] and all zone power are set to [Off].)
STR-DN860:
0.3 W (When [Control for HDMI], [Standby Through],
[Remote Start] and [Bluetooth Standby] are set to
[Off].)
0.5 W (When [Control for HDMI] is set to [On], and
[Standby Through], [Remote Start] and [Bluetooth
Standby] are set to [Off].)
1.7 W (When [Control for HDMI] and [Bluetooth
Standby] are set to [On], and [Standby Through] and
[Remote Start] are set to [Off].)
Dimensions (width/height/depth)
(Approx.)
STR-DN1060:
430 mm × 172 mm × 329.4 mm
(17 in × 6 7/8 in × 13 in)
including projecting parts and controls
STR-DN860:
430 mm × 156 mm × 329.4 mm
(17 in × 6 1/4 in × 13 in)
including projecting parts and controls
Mass (Approx.)
STR-DN1060:
10.4 kg (22 lb 15 oz)
STR-DN860:
8.3 kg (18 lb 5 oz)
Design and specifi cations are subject to change without notice.
Supplied accessories
• Startup Guide
• Help Guide
• Reference Guide (specifications and precautions)
• Remote control (1)
• R03 (size-AAA) batteries (2)
• Optimizer microphone (1)
• FM wire antenna (aerial) (1)
