25
STR-DN860/DN1060
5. Diag (Wireless LAN Test)
This screen performs wireless LAN/Miracast test.
Screen 1: Selects Wireless LAN Test Category
Operation:
[
<
]/[
,
] Selects the category
[
m
]/[ ] Activate the selected category
[RETURN] Returns to service top menu
Screen 2: Selects Wireless LAN Test
Operation:
[1] Show Wireless LAN module Information (Not used)
[2] Connect Access Point (Not used)
[3] Start display RSSI value (Not used)
[4] Start Ping Test (Not used)
[5] Write P2P Address to Registry
[6] P2P Registry Check
[
M
]/[
m
] Selects Test
[ ] Activate and Start Test
[RETURN] Returns to test category selection
Screen 2: Store P2P device address to Registry
Display will show : P2P device address : “xx:xx:xx:xx:xx:xx”
• Viewing the Status display, if
Successful : “Write Successful!”
Fail: “Write Fail!”
Screen 3: P2P Registry Check
Show P2P device address “xx:xx:xx:xx:xx:xx”
Diag
Category: Wireless LAN Test
Diag
Category: Wireless LAN Test
[1] Show WLAN HwInfo
[2] Connect to AccessPoint
[3] Start Display RSSI Value
[4] Start Ping Test
[5] Write P2P address to Registry
[6] P2P Registry Check
P2P device address : xx:xx:xx:xx:xx:xx
Status : Write Successful!
Status : Write Fail!
Diag
Category: Wireless LAN Test
[1] Show WLAN HwInfo
[2] Connect to AccessPoint
[3] Start Display RSSI Value
[4] Start Ping Test
[5] Write P2P address to Registry
[6] P2P Registry Check
P2P device address : xx:xx:xx:xx:xx:xx
HELP: [UP] [DOWN] [ENT] [RET]
(Screen 1)
(Screen 2)
(Screen 3)
6. Diag (MIC Input Test)
This screen performs MIC input test.
Note: Not used for the servicing.
7. Diag (HDMI Input Test)
This screen performs HDMI input test.
Note: Not used for the servicing.
8. Diag (Transcoder Test)
Note: Not used for the servicing.
9. Diag (Bluetooth Device Test)
This screen performs Bluetooth Device Test.
Screen 1: Select Bluetooth Device Test Category
Operation:
[
<
]/[
,
] Selects the category
[ ] Activate the selected category
[RETURN] Returns to the service top menu
Screen 2: Select Bluetooth Device Test
Operation:
[1] Bluetooth Enable
[2] Bluetooth Disable
[3] Write Bluetooth device address to Registry.
[4] Bluetooth Inquiry Test
[
M
]/[
m
] Selects Device
[ ] Activate and Start Test
[RETURN] Returns to the selection of test category
Screen 2: Select [1] Bluetooth Enable
• Viewing the Status display, if
Successful: “Bluetooth Enable Successful!”
Fail: “Bluetooth Enable Fail!”
Screen 3: Select [2] Bluetooth Disable
• Viewing the Status display, if
Successful: “Bluetooth Disable Successful!”
Fail: “Bluetooth Disable Fail!”
Screen 4: Select [3] Write Bluetooth device address to
Registry
Display will show : Bluetooth device address : “xx:xx:xx:xx:xx:xx”
• Viewing the Status display, if
Successful: “Write Successful!”
Fail: “Write Fail!”
To Next Page
