STR-DN860/DN1060
8
NOTE OF REPLACING MB-1409 BOARD OR WLAN/
BT COMBO CARD
When the MB-1409 board or WLAN/BT COMBO card are
replaced, please execute the below service mode.
Procedure:
While pressing [DISPLAY] button, press and release the [MUSIC],
[A.F.D/2CH], [MOVIE] button in order, the message “SERVICE
IN” appears.
Next, go to service menu and execute “[1] Bluetooth Enable” and
“[3] Write Bluetooth device address to Registry”.
Finally check one touch NFC listening function at normal power
on.
Note: The operation in this mode must use a remote commander
and TV monitor.
1. Connect this unit with TV monitor.
2. Press the [
?/1
] button to turn the power on.
3. While pressing [DISPLAY] button, press and release the
[MUSIC], [A.F.D/2CH], [MOVIE] button in order, the
message “SERVICE IN” appears.
4. Enter the SVC service mode. The OSD menu on TV monitor
can be operated by remote commander.
5. Press [m] and Enter Diag.
6. Press [,] and Enter Bluetooth Device Test (Screen 1).
7. Enter [1] Bluetooth Enable, wait until the display show
“ Status : Bluetooth Enable Successful ” (Screen 2).
8. Enter [3] Write Bluetooth device address to Registry, wait until
the display show “Bluetooth Device Address” and “Status :
Write Successfull” (Screen 3).
9. Press the [RETURN] button on the remote commander to
select “Wireless LAN Test” (Screen 4).
10. Press the [ ] button on the remote commander to select
“[5] Write P2P address to Registry”.
11. Press the [ ] button on the remote commander, wait until the
display show “Status: Write Successful!” (Screen 5).
12. Press the [m] button on the remote commander to select
“(6) P2P Registry Check” (Screen 6).
13. Press the [ ] button on the remote commander to check the
P2P device address is the same as shown in Screen 5.
(Displayed characters/values in the following fi gure are
example)
14. Press the [RETURN] button on the remote commander and
select Factory Initialize (go to Screen 7).
15. The set will turn off automatically.
Diag
Category: Bluetooth Device Test
Diag
Category: Bluetooth Device Test
[1] Bluetooth Enable
[2] Bluetooth Disable
[3] Write Bluetooth device address to Registry
[4] Bluetooth Inquiry Test
Status : Bluetooth Enable Successful!
HELP: [UP] [DOWN] [ENT] [RET]
(Screen 1)
(Screen 2)
Diag
Category: Wireless LAN Test
Diag
Category: Wireless LAN Test
[1] Show WLAN HwInfo
[2] Connect to AccessPoint
[3] Start Display RSSI Value
[4] Start Ping Test
[5] Write P2P address to Registry
[6] P2P Registry Check
P2P device address : xx:xx:xx:xx:xx:xx
Status : Write Successful!
Status : Write Fail!
Diag
Category: Wireless LAN Test
[1] Show WLAN HwInfo
[2] Connect to AccessPoint
[3] Start Display RSSI Value
[4] Start Ping Test
[5] Write P2P address to Registry
[6] P2P Registry Check
P2P device address : xx:xx:xx:xx:xx:xx
HELP: [UP] [DOWN] [ENT] [RET]
(Screen 4)
(Screen 5)
(Screen 6)
(Screen 7)
(Screen 3)
Diag
Category: Bluetooth Device Test
[1] Bluetooth Enable
[2] Bluetooth Disable
[3] Write Bluetooth device address to Registry
[4] Bluetooth Inquiry Test
Bluetooth device address : 00:01:36:23:FD:CF
Status : Write Successful!
HELP: [UP] [DOWN] [ENT] [RET]
Service Mode Menu
[1] Diag
[2] Log
[3] Factory Initialize
[4] Network --
>
Not Support In This Model
[5] Version Up
[6] System Information
[7] EMC Test Mode
[8] Drive --
>
Not Support In This Model
[9] HDD mode
[10] RF Test Mode
HELP: [DOWN] [ENT]
