STR-DN860/DN1060
99
Pin No. Pin Name I/O Description
AH13 RCKE O Clock enable signal output to the SD-RAM
AH14 RDQ2 I/O Two-way data bus with the SD-RAM
AH16 RDQS0_ O Data strobe signal (negative) output to the SD-RAM
AH17 RCLK0_ O Clock signal (negative) output to the SD-RAM
AH18 RDQS1 O Data strobe signal (positive) output to the SD-RAM
AH19 RDQM0 O Data mask signal output to the SD-RAM
AH20 RDQ6 I/O Two-way data bus with the SD-RAM
AH22,
AH23
NFD5, NFD3 I/O Two-way data bus with the NAND fl ash
AH25 OPWRSB O Power control signal output to the system controller
AH26 UATXD - Not used
AH27 VSTB - Not used
AH28 IR - Not used
