When using this Zone 3 connection, you need to set up the SPEAKERS
SURROUND/ZONE 3 terminals.
Only audio signals from [USB], [Bluetooth] (while in BLUETOOTH RX mode only), [Home
Network], [Music Services], [FM TUNER] and audio signals input from AUDIO IN jacks
are output to the Zone 3 speakers.
External digital input from OPTICAL IN, COAXIAL IN, HDMI IN jacks and Screen mirroring
cannot be output to Zone 3.
[106] Using the Multi-Zone Features (for STR-DN1060 only)
Enjoying sound from
speakers located in other rooms (for STR-DN1060 only)
2. Assigning speakers for Zone 2 (for STR-DN1060 only)
You can assign the speakers installed in Zone 2 as Zone 2 speakers.
Follow the procedure below after connecting the speakers installed in Zone 2 to the
SPEAKERS SURROUND BACK/BI-AMP/FRONT HIGH/FRONT B/ZONE 2 terminals of the
receiver.
1. Select [Setup] - [Speaker Settings] from the home menu.
2. Select [Speaker Pattern].
3. Select one of the following speaker patterns displayed on the TV screen:
3/2.1, 3/2, 2/2.1, 2/2, 3/0.1, 3/0, 2/0.1 or 2/0, and select [Save].
4. Select [Sur Back SP Assign] - [Zone2].
Note
If a speaker pattern with surround back speakers or front high speakers is set, you cannot
set the SPEAKERS SURROUND BACK/BI-AMP/FRONT HIGH/FRONT B/ZONE 2
terminals for a bi-amplifier connection or a Zone 2 connection.
[107] Using the Multi-Zone Features (for STR-DN1060 only)
Enjoying sound from
speakers located in other rooms (for STR-DN1060 only)
3. Assigning speakers for Zone 3 (for STR-DN1060 only)
You can assign the speakers installed in Zone 3 as Zone 3 speakers.
