– 34 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
D906 8-719-911-19 DIODE 1SS119
D907 8-719-911-19 DIODE 1SS119
D908 8-719-911-19 DIODE 1SS119
D910 8-719-986-56 DIODE HZS24-3LTA
D911 8-719-200-82 DIODE 11ES2
D912 8-719-911-19 DIODE 1SS119
D923 8-719-911-19 DIODE 1SS119
D924 8-719-911-19 DIODE 1SS119
< IC >
IC901 8-759-352-00 IC TMP47C200BN-H351
IC902 8-759-188-67 IC X24C01P-S
IC903 8-759-962-08 IC BA6208
IC905 8-759-635-63 IC M51943BSL
< TRANSISTOR >
Q901 8-729-900-63 TRANSISTOR DTA124ES
Q902 8-729-900-63 TRANSISTOR DTA124ES
Q903 8-729-900-63 TRANSISTOR DTA124ES
Q904 8-729-900-63 TRANSISTOR DTA124ES
Q905 8-729-201-53 TRANSISTOR 2SA1015-GR
Q906 8-729-620-05 TRANSISTOR 2SC2603-EF
Q911 8-729-900-63 TRANSISTOR DTA124ES
Q912 8-729-119-76 TRANSISTOR 2SA1175-HFE
< RESISTOR >
R302 1-259-502-11 CARBON 4.7M 5% 1/4W
R303 1-259-183-11 CARBON 4.7K 5% 1/4W
R304 1-259-171-21 CARBON 1.5K 5% 1/4W
R305 1-259-502-11 CARBON 4.7M 5% 1/4W
R306 1-259-199-11 CARBON 22K 5% 1/4W
R307 1-259-183-11 CARBON 4.7K 5% 1/4W
R308 1-259-183-11 CARBON 4.7K 5% 1/4W
R309 1-259-199-11 CARBON 22K 5% 1/4W
R402 1-259-502-11 CARBON 4.7M 5% 1/4W
R403 1-259-183-11 CARBON 4.7K 5% 1/4W
R404 1-259-171-21 CARBON 1.5K 5% 1/4W
R405 1-259-502-11 CARBON 4.7M 5% 1/4W
R406 1-259-199-11 CARBON 22K 5% 1/4W
R407 1-259-183-11 CARBON 4.7K 5% 1/4W
R408 1-259-183-11 CARBON 4.7K 5% 1/4W
R409 1-259-199-11 CARBON 22K 5% 1/4W
R901 1-249-433-11 CARBON 22K 5% 1/4W
R902 1-249-433-11 CARBON 22K 5% 1/4W
R903 1-249-433-11 CARBON 22K 5% 1/4W
R904 1-249-433-11 CARBON 22K 5% 1/4W
R905 1-249-433-11 CARBON 22K 5% 1/4W
R906 1-249-433-11 CARBON 22K 5% 1/4W
R907 1-249-425-11 CARBON 4.7K 5% 1/4W
R908 1-249-425-11 CARBON 4.7K 5% 1/4W
R909 1-249-425-11 CARBON 4.7K 5% 1/4W
R910 1-249-429-11 CARBON 10K 5% 1/4W
R911 1-249-429-11 CARBON 10K 5% 1/4W
R912 1-249-433-11 CARBON 22K 5% 1/4W
R913 1-249-433-11 CARBON 22K 5% 1/4W
R914 1-249-429-11 CARBON 10K 5% 1/4W
R915 1-249-433-11 CARBON 22K 5% 1/4W
R916 1-249-425-11 CARBON 4.7K 5% 1/4W
R917 1-249-429-11 CARBON 10K 5% 1/4W
R918 1-249-429-11 CARBON 10K 5% 1/4W
R919 1-249-429-11 CARBON 10K 5% 1/4W
R920 1-249-429-11 CARBON 10K 5% 1/4W
R921 1-249-429-11 CARBON 10K 5% 1/4W
R922 1-249-429-11 CARBON 10K 5% 1/4W
R923 1-247-807-31 CARBON 100 5% 1/4W
R924 1-247-807-31 CARBON 100 5% 1/4W
R925 1-247-807-31 CARBON 100 5% 1/4W
R926 1-247-807-31 CARBON 100 5% 1/4W
R927 1-247-807-31 CARBON 100 5% 1/4W
R928 1-247-807-31 CARBON 100 5% 1/4W
R929 1-247-753-11 CARBON 1.2K 5% 1/2W
R930 1-247-843-11 CARBON 3.3K 5% 1/4W
R933 1-247-753-11 CARBON 1.2K 5% 1/2W
R934 1-249-409-11 CARBON 220 5% 1/4W
R935 1-249-409-11 CARBON 220 5% 1/4W
R936 1-247-752-11 CARBON 1K 5% 1/2W
R937 1-247-753-11 CARBON 1.2K 5% 1/2W
R938 1-247-753-11 CARBON 1.2K 5% 1/2W
R939 1-247-752-11 CARBON 1K 5% 1/2W
R940 1-249-435-11 CARBON 33K 5% 1/4W
R941 1-249-400-11 CARBON 39 5% 1/4W
R942 1-247-843-11 CARBON 3.3K 5% 1/4W
R999 1-249-433-11 CARBON 22K 5% 1/4W
< VARIABLE RESISTOR >
RV301 1-225-615-11 RES, VAR, CARBON 250K/250K (BALANCE)
RV302 1-225-614-11 RES, VAR, CARBON 250K/250K (TREBLE)
RV303 1-225-613-11 RES, VAR, CARBON 900K/900K (BASS)
< SWITCH >
S301 1-571-828-11 SWITCH, PUSH (1 KEY) (SOURCE DIRECT)
S302 1-762-394-11 SWITCH, PUSH (1 KEY) (MUTING)
S901 1-771-506-11 SWITCH, ROTARY (SPEAKERS)
S903 1-762-183-11 SWITCH, ROTARY (INPUT SELECTOR)
< VIBRATOR >
X900 1-579-223-11 OSCILLATOR, CERAMIC (8MHz)
************************************************************
* A-4407-672-A PHONO BOARD, COMPLETE
***********************
< CAPACITOR >
C150 1-102-978-00 CERAMIC 220PF 5% 50V
C151 1-126-059-11 ELECT 10uF 20% 50V
C152 1-101-880-00 CERAMIC 47PF 5% 50V
C153 1-106-359-00 MYLAR 4700PF 5% 200V
C154 1-126-024-11 ELECT 220uF 20% 16V
C155 1-130-341-00 FILM 0.056uF 3% 100V
C156 1-130-971-00 FILM 0.016uF 3% 100V
C157 1-126-059-11 ELECT 10uF 20% 50V
C170 1-126-023-11 ELECT 100uF 20% 25V
C171 1-136-165-00 FILM 0.1uF 5% 50V
C172 1-136-165-00 FILM 0.1uF 5% 50V
C250 1-102-978-00 CERAMIC 220PF 5% 50V
C251 1-126-059-11 ELECT 10uF 20% 50V
PANEL PHONO
