– 35 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C252 1-101-880-00 CERAMIC 47PF 5% 50V
C253 1-106-359-00 MYLAR 4700PF 5% 200V
C254 1-126-024-11 ELECT 220uF 20% 16V
C255 1-130-341-00 FILM 0.056uF 3% 100V
C256 1-130-971-00 FILM 0.016uF 3% 100V
C257 1-126-059-11 ELECT 10uF 20% 50V
< CONNECTOR >
CN151 1-691-768-11 PLUG (MICRO CONNECTOR) 6P
< DIODE >
D170 8-719-985-97 DIODE HZS7B1LTA
< IC >
IC150 8-759-701-25 IC NJM2068D-D
< JACK >
J150 1-784-933-11 JACK 2P (PHONO IN)
< TRANSISTOR >
Q150 8-729-354-52 TRANSISTOR 2SC2545
Q151 8-729-354-52 TRANSISTOR 2SC2545
Q250 8-729-354-52 TRANSISTOR 2SC2545
Q251 8-729-354-52 TRANSISTOR 2SC2545
< RESISTOR >
R151 1-249-911-11 CARBON 330 5% 1/4W
R152 1-259-215-21 CARBON 100K 5% 1/4W
R153 1-259-215-21 CARBON 100K 5% 1/4W
R154 1-259-161-21 CARBON 560 5% 1/4W
R155 1-259-161-21 CARBON 560 5% 1/4W
R156 1-259-143-21 CARBON 100 5% 1/4W
R157 1-259-191-21 CARBON 10K 5% 1/4W
R158 1-249-900-11 CARBON 110 5% 1/4W
R159 1-249-844-11 CARBON 56K 1% 1/2W
R160 1-259-320-11 CARBON 4.7K 1% 1/2W
R161 1-259-239-11 CARBON 1M 5% 1/4W
R162 1-259-167-21 CARBON 1K 5% 1/4W
R168 1-259-143-21 CARBON 100 5% 1/4W
R169 1-259-115-11 CARBON 6.8 5% 1/4W
R170 1-259-171-21 CARBON 1.5K 5% 1/4W
R251 1-249-911-11 CARBON 330 5% 1/4W
R252 1-259-215-21 CARBON 100K 5% 1/4W
R253 1-259-215-21 CARBON 100K 5% 1/4W
R254 1-259-161-21 CARBON 560 5% 1/4W
R255 1-259-161-21 CARBON 560 5% 1/4W
R256 1-259-143-21 CARBON 100 5% 1/4W
R257 1-259-191-21 CARBON 10K 5% 1/4W
R258 1-249-900-11 CARBON 110 5% 1/4W
R259 1-249-844-11 CARBON 56K 1% 1/2W
R260 1-259-320-11 CARBON 4.7K 1% 1/2W
R261 1-259-239-11 CARBON 1M 5% 1/4W
R262 1-259-167-21 CARBON 1K 5% 1/4W
R268 1-259-143-21 CARBON 100 5% 1/4W
R269 1-259-115-11 CARBON 6.8 5% 1/4W
< SWITCH >
S101 1-762-395-11 SWITCH, PUSH (1 KEY) (PHONO CARTRIDGE)
************************************************************
* 1-669-481-11 POWER LED BOARD
****************
< CONNECTOR >
CN900 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
< DIODE >
D913 8-719-313-40 LED SEL1516W (POWER)
< IC >
IC904 8-749-014-66 IC NJL56H400A
< RESISTOR >
R931 1-249-408-11 CARBON 180 5% 1/4W
************************************************************
* 1-669-473-11 PS BOARD
*********
< CAPACITOR >
C750 1-125-939-11 ELECT 10000uF 20% 56V
C751 1-125-939-11 ELECT 10000uF 20% 56V
C756 1-136-880-11 FILM 2.2uF 10% 160V
< CONNECTOR >
CN1 1-774-108-11 PIN, CONNECTOR (PC BOARD)
CN2 1-564-321-00 PIN, CONNECTOR 2P
CN3 1-564-321-00 PIN, CONNECTOR 2P
* CN750 1-564-687-11 PIN, CONNECTOR 3P
* CN751 1-766-920-11 PIN, CONNECTOR 4P
CN752 1-770-832-11 CONNECTOR, BOARD TO BOARD 6P
< DIODE >
D751 8-719-230-02 DIODE 30DF2
D752 8-719-230-02 DIODE 30DF2
D753 8-719-230-02 DIODE 30DF2
D754 8-719-230-02 DIODE 30DF2
< FUSE >
! F1 1-532-504-51 FUSE T4AL/250V
< FUSE HOLDER >
FH1 1-533-233-11 HOLDER, FUSE
FH2 1-533-233-11 HOLDER, FUSE
< RESISTOR >
! R750 1-212-974-00 FUSIBLE 47 5% 1/2W F
************************************************************
PHONO POWER LED PS
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
