25
Chapter 2 Menu
Preset Adjustment of the Picture Level Control
Knobs — CONTROL PRESET ADJ Menu
The preliminary adjustment of contrast, brightness,
chroma, and phase are carried out with the CONTROL
PRESET ADJ menu to set the preset values to the
knobs for the above-mentioned adjustments.
Preset values can be set in the following ways:
•Adjustment with the MANUAL knobs
•Automatic adjustment (An external color bar signal is
necessary.)
•Copying data from other BVM-series monitors that
have been connected via the serial remote connector,
or from data stored in monitor memory cards.
This section explains the setting lists displayed in the
menu.
How to read the setting lists
•For purposes of explanation, each setting list is
preceded by a menu number. These numbers are not
displayed on the screen.
For more information about the menu number, see “About
menu numbers” on page 19.
•The arrow mark (÷) refers you to another setting list
that appears after you make the setting, or to an
operation that is carried out as a result of the setting.
When there is no arrow mark, the menu does not have
any sub-list.
[A] CONTROL PRESET ADJ menu
Select the setting method.
MANUAL: Set with the MANUAL knobs. ÷[A1]
AUTO: Set by automatic adjustment. ÷[A2]
COPY: Copy data from elsewhere. ÷[A3]
Overview
[A1] MANUAL menu
Adjust values by turning the CHROMA, BRIGHT,
CONTRAST and/or PHASE knobs. After the
adjustment, press the ENTER button to confirm the
adjusted values.
PHASE: xxxx
CHROMA: xxxx
BRIGHT: xxxx
CONTRAST: xxxx
When you want to erase characters from the screen
while adjusting manually
Press the [F1] button. The characters disappear. To
display characters, press the [F1] button again.
To reset the setting to the default
Press the corresponding MANUAL button. The
adjusted value is reset to 1000 (default).
Setting Lists in the CONTROL PRESET ADJ Menu
Structure of the CONTROL PRESET ADJ Menu
[A]
Level 1 Level 2
MANUAL [A1] FULL FIELD CB 100
AUTO [A2] FF CB 75 (WHITE 100)
SMPTE CB
EIA CB
COPY [A3] OTHER MONITOR [A31]
MEMORY CARD [A32]
26
Chapter 2 Menu
[A2] AUTO menu
Select the color bar signal to be used for automatic
adjustment. ÷Adjustment is carried out.
FULL FIELD CB 100: 100% full-field color bar
FF CB 75 (WHITE 100): 75% full-field color bar
(with 100 % white signal)
SMPTE CB: SMPTE standard color bar
EIA CB: EIA standard color
[A3] COPY menu
Select the source to be copied from.
OTHER MONITOR: Copy data from another
monitor. ÷[A31]
MEMORY CARD: Copy data from a memory card.
÷[A32]
[A31] OTHER MONITOR menu
Input the address of the monitor from which the data
will be copied. ÷ Copy is carried out.
MONITOR ADDRESS: Input the address.
[A32] MEMORY CARD menu
Select the file name. ÷ Copy is carried out.
FILE NAME: Select the file name.
Preset Adjustment of the Picture Level Control Knobs — CONTROL
PRESET ADJ Menu
