Specifications
Appendixes
Specifications
General
System 15.625 kHz - 45 kHz (For details, see
“Available Signal Systems” on page
58.)
CRT
Super fine pitch Trinitron, 4:3 aspect ratio
Aperture grille pitch:
0.3 mm, 90 degree deflection, Ø30.6 mm
diameter in-line gun
Effective picture size
With 16:9 aspect ratio:
386 × 218 mm (15
1
/4 × 8
5
/8 inches)
(w/h)
443 mm (17
1
/2 inches) (diagonal size)
With 4:3 aspect ratio:
386 × 291 mm (15
1
/4 × 11
1
/2 inches)
(w/h)
482 mm (19 inches) (diagonal size)
CRT protection: EHT (extremely high tension)
protection type
Warm-up time:
approx. 30 minutes
Anode voltage:
27 kV with no beam current
Nominal chromaticity coordinates:
SMPTE C phosphor (BVM-A20F1U)
EBU phosphor (BVM-A20F1M/A20F1A)
Error: ± 0.005 or less
Power consumption
200 W (When an optional adaptor is
installed)
Power requirements
100 to 240 V AC, 2.1 to 0.9 A,
50/60 Hz
Peak inrush current
1 Power ON, current probe method: 47
A (240 V)
2 Hot switching inrush current,
measured in accordance with
European standard EN55103-1 22 A
(230 V)
Mass approx. 40 kg (88 lb 3 oz)
Input/output connectors
Control
OPTION: Mini-DIN 8-pin (female) × 1
PARALLEL REMOTE: D-sub 9-pin
(female) × 1
SERVICE: D-sub 9-pin (male) × 1
LAN (10BASE-T/100BASE-TX):
RJ-45 × 1
DC 5V OUT: Circle 4-pin (female) × 1
xy
R
0.630 0.340
G
0.310 0.595
B
0.155 0.070
xy
R
0.640 0.330
G
0.290 0.600
B
0.150 0.060
