Sony TRINITRON KV-21FA310 - Page 21

KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
21
KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
NTSC
Init
Data
VAR
1 VSIZ
V RAMP SIZE
55
VAR
2 VPOS
V POSITION ( RAMP DC )
37
VAR
3VLIN
V LINEARITY
30
VAR
4SCOR
S CORRECTION
20
VAR
5TRAP
EW TRAPESIUM
30
VAR
6 PAMP
PARABOLA ( EW PIN )
0
VAR
7UPIN
UPPER CORNER ( UPPER PIN )
34
VAR
8LPIN
LOWER CORNER ( LOWER PIN )
32
VAR
9 ABLG
ABL GAIN
15
VAR
10 SCON
SUB CONTRAST LEVEL
10
VAR
11 VPW
JUMP PULSE WIDTH
1
NTSC
Init Video YUV 16:09
Data
VAR
1 RDRV
R DRIVE
45 45 45
N/A
VAR 2 GDRV
G DRIVE: GDOF OFFSET ( only Color Temp. "Warm")
28 28 30 N/A
VAR 3 BDRV
B DRIVE: BDOF OFFSET ( only Color Temp. "Warm")
33 33 29 N/A
VAR
4 RCUT
HARDWARE AKB (R) CMP DATA
120
120 120 N/A
VAR 5 GCUT
HARDWARE AKB (G) CMP DATA
98 98 72 N/A
VAR 6 BCUT
HARDWARE AKB (B) CMP DATA
102 102 91 N/A
VAR
7SCON
SUB CONTRAST LEVEL
16 16 16
N/A
VAR
8 SHUE
SUB TINT (HUE)
77 7
N/A
VAR
9SCOL
SUB COLOR LEVEL
17 17
27 N/A
VAR
10 SBRT
SUB BRIGHTNESS
11 11
14 N/A
FIX 11 RON
R OUTPUT ON ( 0:R OUTPUT OFF 1:R OUTPUT ON )
1
FIX 12 GON
G OUTPUT ON ( 0:R OUTPUT OFF 1:R OUTPUT ON )
1
FIX 13 BON
B OUTPUT ON ( 0:R OUTPUT OFF 1:R OUTPUT ON )
1
Fix/ Var No.
Service
Group
Item name & ( Description )Name
Name Item name & ( Description )No.
VP1
Service
Group
Fix/ Var
16 : 9
