Sony TRINITRON KV-21FA310 - Service Data Lists

KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
20
KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
4-4. SERVICE DATA LISTS
NTSC
Init
Data
VERSION Fix 0 VER
Micro
p
rocessor version information
=
VAR
1HSIZ
H-SIZE ( EW DC : YUV OFFSET )
29
VAR
2HPOS
H POSITION: YUV OFFSET
37
VAR
3 VSIZ
V RAMP SIZE: YUV OFFSET
35
VAR 4 VPOS
V POSITION (RAMP DC) NOT USEFUL: YUV OFFSET
33
VAR
5VLIN
V LINEARITY
31
VAR
6SCOR
S CORRECTION
26
VAR
7 VBOW
BOW
37
VAR
8 VANG
ANGLE
31
VAR
9TRAP
EW TRAPESIUM
25
VAR
10 PAMP
PARABOLA ( EW PIN )
9
VAR
11 UPIN
UPPER CORNER ( UPPER PIN )
32
VAR
12 LPIN
LOWER CORNER ( LOWER PIN )
32
VAR
13 TROT
TROT
109
VAR
14 HBL
K
FBPBLK ( H BLK MODE SELECT )
0
VAR
15 RBL
K
HBLK R POS ( HBLK REAR TIMING: YUV OFFSET )
15
VAR
16 LBL
K
HBLK F POS ( HBLK FRONT TIMING: YUV OFFSET )
48
FIX
17 VBL
K
VBLK POS ( V BLK WIDTH )
0
FIX 18 HMSK
Macro OFF ( TOP VEND [ WHEN MACROVISION ] PREVENT
OFF )
0
FIX
19 HDW
IIC_HOUT_DUTY ( H PULSE WIDTH [ 25u/19u ]
1
FIX
20 AFC
H AFC Gain ( AFC GAIN )
0
FIX
21 AFC1
H Charge pump ( AFC1 TIME CONSTANT )
3
FIX
22 AFCW
AFC1 PULLIN ( AFC1 PULL IN WIDE )
0
FIX
23 CDMD
V CD MODE ( V DET WINDOW SW TIMING )
1
FIX
24 HSS
SYNC SLICE LVL(H) ( SYNC SLICE LEVEL [ H sepa ] )
0
FIX
25 VSS
SYNC SLICE LVL(L) ( SYNC SLICE LEVEL [ V sepa ] )
3
FIX
26 SLDN
AUTO SLICE DOWN ( AUTO SLICE LEVEL DOWN )
0
FIX
27 SLUP
AUTO SLICE UP ( AUTO SLICE LEVEL UP )
0
FIX
28 JPSW
VJPSW ( JUMP SW )
0
FIX 29 HOSC
H VCO FOR OFFSET ADJUST OFFSET
5
FIX
30 EHT
EHT
4
FIX
31 EHTG
EHT GAIN ( EHT MODE )
1
DescriptionFix/ Var No. Name
Service
Group
DEF
