KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
25
KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
PALLET
= VIVID
PALLET
= STD
PALLET
= MOVIE
PALLET
= PRO
FIX
1 VPIC
63 50 37 31
FIX
2 VBRI
BRIGHTNESS
27 30 31 31
FIX
3VCOL
COLOR
37 32 31 31
FIX
4 VHUE
HUE
31 31 31 31
FIX
5 VSHA
SHARPNESS
31 32 31 21
FIX
6 VVM
VM
21 0 0
FIX
7VTRI
COLOR TEMP
01 2 1
FIX
8 VAPA
APERTURE G
55 3 0
FIX
9VGMA
GAMMA
31 0 0
FIX
10 VDCT
DCT LV
23 15 2 2
FIX 11 VBKP
BLACK STRETCH DEPTH ( VIDEO )
33 4 7
FIX 12 TBKD
BLACK STRETCH DEPTH ( TUNER )
33 4 7
NTSC
Init
Data
FIX 1 YNRS
YNR SW
(
YNR ON
)
0
FIX 2 YTHR
Y THR 2D
(
Y SIGNAL THROUGH 2DYCS
)
0
FIX 3 Y2D
Y2D Fix
(
Y SIGNAL GENERATE from 2DYCS
)
0
FIX 4 2DFX
C BPF Fix
(
C SIGNAL GENERATE from H/V BPF onl
y
1
FIX 5 CLPS
CLAMP CONTROL SW ( 0: CLAMP OFF. 1:
CLAMP AUTO. 2: CLAMP ON
]
1
FIX 6 VLPF
VIDEO LPF
(
Y_LPF [ ANALOG ] for ad
j
ust
)
3
FIX 7 CLPF
CHROMA LPF
(
C_LPF [ ANALOG ] for ad
j
ust
)
3
FIX 8 BPFB
YCS HBPF BACK
(
YCS HBPF SELECT [ BACK ]
)
1
FIX 9 BPFF
YCS HBPF FRONT
(
YCS HBPF SELECT [ FRONT ]
)
1
FIX 10 BKTS
BS T2 IFON
(
BLACK STRETCH RECOVER TIME OUT
0
FIX 11
VMG
2
VMGAIN
2
( MODULATOR FEEDBACK GAIN CONTROL
2
FIX 12 CLPT
CLAMP KEEP TIMER ( CLAMP AUTO ON KEEP TIMER COUNT [
@ 100 MS
])
15
