KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
32
KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
NTSC
21FA310 20FS120 21FM120 24FS120
VAR
1 SBAL
SBAL ( SUB BALANCE )
44 4 4
VAR
2 SBAS
SBAS ( SUB BASS )
06 4 7
VAR
3STRE
STRE ( SUB TREBLE )
07 7 7
VAR
4SRL
SRL ( SURROUND LEVEL )
00 0 0
VAR
5 BBOL
BBOL ( SURROUND OFF-BBE LOW )
40 0 0
VAR
6 BBOH
BBOH ( SURROUND OFF-BBE HIGH)
70 0 0
VAR
7 BBSL
BBSL ( SIMULATE BBE LOW )
20 0 0
VAR
8 BBSH
BBSH ( SIMULATE BBE HIGH )
70 0 0
VAR
9 BBGL
BBGL ( WOW GAME BBE LOW )
40 0 0
VAR
10 BBGH
BBGH ( WOW GAME BBE HIGH )
90 0 0
VAR
11 BBTL
BBTL ( SRS BBE LOW )
00 0 0
VAR
12 BBTH
BBTH ( SRS BBE HIGH )
00 0 0
VAR
13 BBDL
BBDL ( Audio Processor Prologic BBE Low for DOLBY )
30 0 0
VAR
14 BBDH
BBDH ( Audio Processor Prologic BBE High for DOLBY )
5
000
VAR
15 VFIX
VFIX ( AUDIO OUTPUT FIX DATA )
00 0 0
VAR
16 AGCL
AGCL ( AGC LEVEL )
22 2 2
VAR
17 VCOF
RF OFFSET DATA
99 9 9
NTSC
21FA310 20FS120 21FM120 24FS120
VAR
1 BBEL
SUB AUDIO PROCESSOR PROLOGIC BBE LOW
20 0 0
VAR
2 BBEH
SUB AUDIO PROCESSOR PROLOGIC BBE HIGH
50 0 0
VAR
3 BBOL
SURROUND OFF-BBE LOW
20 0 0
VAR
4 BBSL
SIMULATE BBE LOW
20 0 0
VAR
5 BBGL
WOW GAME BBE LOW
30 0 0
VAR
6AGCL
SUB AUDIO PROCESSOR AGC LEVEL
20 0 0
VAR
7 DDOF
DOLBY OFFSET DATA
15 0 0 0
Name Item name & ( Description )
Service
Group
Fix/ Var
No. Name
No.
AUDIO
PROCESSOR
Item name & ( Description )
AP2
Service
Group
Fix/ Var
