Sony TRINITRON KV-21FA310 - Page 46

46
KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
CV BOARD IC
VOLTAGE LIST
PIN VOLT PIN VOLT
11.812.0
22.822.0
34.432.4
4GND4GND
54.853.7
6 4.8 6 200.0
7 4.8 7 136.0
8 9.0 8 142.0
9 140.0
IC701 IC1751
All voltages are in V.
CV BOARD TRANSISTOR LIST
BCE BCE
Q761 2.2 3.8 2.9 Q783 2.1 9.0 2.7
Q762 3.1 9.0 3.8 Q901 0.9 67.0 0.4
Q763 2.0 9.0 2.6 Q902 134.0 67.0 134.0
Q771 2.2 3.8 2.9 Q903 1.8 5.4 2.4
Q772 3.2 9.0 3.8 Q904 1.8 9.0 2.4
Q773 2.0 9.0 2.6 Q905 5.7 GND 5.4
Q781 2.2 3.9 2.9 Q906 5.7 9.0 6.1
Q782 3.3 9.0 3.9 Q1772 0.0 0.0 0.0
All voltages are in V.
