Sony TRINITRON KV-21FA310 - Page 69

69
KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
R109 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(ALL EXCEPT KV-21FM120)
R110 1-249-409-11 CARBON 220 5% 1/4W
R111 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(ALL EXCEPT KV-21FM120)
R112 1-249-425-11 CARBON 4.7K 5% 1/4W
R115 1-216-817-11 METAL CHIP 470 5% 1/10W
R116 1-216-853-11 METAL CHIP 470K 5% 1/10W
R200 1-216-813-11 METAL CHIP 220 5% 1/10W
R202 1-216-845-11 METAL CHIP 100K 5% 1/10W
R203 1-216-845-11 METAL CHIP 100K 5% 1/10W
R206 1-216-845-11 METAL CHIP 100K 5% 1/10W
(KV-21FA310LN/21FA310LS ONLY)
R207 1-216-845-11 METAL CHIP 100K 5% 1/10W
(KV-21FA310LN/21FA310LS ONLY)
R208 1-249-409-11 CARBON 220 5% 1/4W
(KV-21FA310LN/21FA310LS ONLY)
R209 1-249-409-11 CARBON 220 5% 1/4W
(KV-21FA310LN/21FA310LS ONLY)
R215 1-216-853-11 METAL CHIP 470K 5% 1/10W
(KV-21FA310LN/21FA310LS ONLY)
R216 1-216-853-11 METAL CHIP 470K 5% 1/10W
(KV-21FA310LN/21FA310LS ONLY)
R217 1-249-409-11 CARBON 220 5% 1/4W
(KV-21FA310LN/21FA310LS ONLY)
R218 1-216-813-11 METAL CHIP 220 5% 1/10W
R220 1-216-813-11 METAL CHIP 220 5% 1/10W
R221 1-249-409-11 CARBON 220 5% 1/4W
R222 1-249-409-11 CARBON 220 5% 1/4W
R226 1-218-285-11 METAL CHIP 75 5% 1/10W
(KV-21FA310LN/21FA310LS ONLY)
R227 1-218-285-11 METAL CHIP 75 5% 1/10W
(KV-21FA310LN/21FA310LS/24FS120/25FS120LN/25FS120LS ONLY)
R229 1-218-285-11 METAL CHIP 75 5% 1/10W
(KV-21FA310LN/21FA310LS/24FS120/25FS120LN/25FS120LS ONLY)
R230 1-218-285-11 METAL CHIP 75 5% 1/10W
R234 1-216-864-11 SHORT CHIP
(KV-21FM120 ONLY)
R250 1-216-821-11 METAL CHIP 1K 5% 1/10W
R251 1-216-821-11 METAL CHIP 1K 5% 1/10W
R301 1-216-864-11 SHORT CHIP
(KV-20FS120/21FS12LN/21FM120/21FS120LS ONLY)
R302 1-216-864-11 SHORT CHIP
(KV-20FS120/21FS12LN/21FM120/21FS120LS ONLY)
R303 1-216-863-11 METAL CHIP 3.3M 5% 1/10W
(ALL EXCEPT KV-21FM120)
R305 1-218-285-11 METAL CHIP 75 5% 1/10W
(ALL EXCEPT KV-21FM120)
R305 1-216-864-11 SHORT CHIP
(KV-21FM120 ONLY)
R308 1-216-821-11 METAL CHIP 1K 5% 1/10W
R309 1-216-833-11 METAL CHIP 10K 5% 1/10W
R310 1-216-821-11 METAL CHIP 1K 5% 1/10W
R311 1-216-813-11 METAL CHIP 220 5% 1/10W
R312 1-218-867-11 METAL CHIP 6.8K 0.50% 1/10W
R313 1-216-864-11 SHORT CHIP
R314 1-216-833-11 METAL CHIP 10K 5% 1/10W
R315 1-216-813-11 METAL CHIP 220 5% 1/10W
R316 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R317 1-216-813-11 METAL CHIP 220 5% 1/10W
R318 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R319 1-216-813-11 METAL CHIP 220 5% 1/10W
R320 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R321 1-247-807-31 CARBON 100 5% 1/4W
R322 1-218-684-11 METAL CHIP 470 0.50% 1/10W
R323 1-215-415-00 METAL 560 1% 1/4W
R324 1-216-821-11 METAL CHIP 1K 5% 1/10W
R325 1-216-864-11 SHORT CHIP
R326 1-400-427-21 FERRITE 0µH
R328 1-400-427-21 FERRITE 0µH
R335 1-216-813-11 METAL CHIP 220 5% 1/10W
R337 1-216-801-11 METAL CHIP 22 5% 1/10W
R338 1-216-864-11 SHORT CHIP
R351 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R352 1-216-853-11 METAL CHIP 470K 5% 1/10W
R363 1-218-285-11 METAL CHIP 75 5% 1/10W
(ALL EXCEPT KV-21FM120)
R363 1-216-864-11 SHORT CHIP
(KV-21FM120 ONLY)
R364 1-218-285-11 METAL CHIP 75 5% 1/10W
(ALL EXCEPT KV-21FM120)
R364 1-216-864-11 SHORT CHIP
(KV-21FM120 ONLY)
R370 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R371 1-216-849-11 METAL CHIP 220K 5% 1/10W
R372 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R382 1-216-863-11 METAL CHIP 3.3M 5% 1/10W
(ALL EXCEPT KV-21FM120)
A
