Sony TRINITRON KV-21FA310 - Page 77

77
KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
C2481 1-162-968-11 CERAMIC CHIP 0.0047µF 10% 50V
C2482 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2484 1-130-495-00 MYLAR 0.1µF 5% 50V
C2485 1-130-495-00 MYLAR 0.1µF 5% 50V
C2486 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C2487 1-127-715-91 CERAMIC CHIP 0.22µF 10% 16V
C2488 1-162-968-11 CERAMIC CHIP 0.0047µF 10% 50V
C2489 1-127-715-91 CERAMIC CHIP 0.22µF 10% 16V
C2490 1-104-665-11 ELECT 100µF 20% 25V
C2493 1-126-935-11 ELECT 470µF 20% 16V
C2494 1-126-935-11 ELECT 470µF 20% 16V
C2495 1-126-935-11 ELECT 470µF 20% 16V
C2496 1-126-935-11 ELECT 470µF 20% 16V
C2499 1-164-315-11 CERAMIC CHIP 470pF 5% 50V
CONNECTOR
* CN2401 1-564-510-11 PLUG, CONNECTOR 7P
* CN2402 1-564-508-11 PLUG, CONNECTOR 5P
DIODE
D2400 8-719-404-50 DIODE MA111-TX
D2401 8-719-070-60 DIODE PDZ7.5B-115
IC
IC2401 6-705-054-01 IC TDA8947J
IC2402 8-759-100-96 IC UPC4558G2
IC2403 6-706-034-01 IC NJW1164M-TE2
IC2404 8-759-165-01 IC NJM2177AFG1
IC2405 8-759-686-15 IC NJM2180M (TE2)
CHIP CONDUCTOR
JR2401 1-216-864-11 SHORT CHIP
JR2402 1-216-864-11 SHORT CHIP
JR2410 1-216-864-11 SHORT CHIP
JR2411 1-216-864-11 SHORT CHIP
JR2420 1-216-864-11 SHORT CHIP
JR2421 1-216-864-11 SHORT CHIP
IC LINK
PS2401 1-576-337-21 IC LINK 2.7A 50V
TRANSISTOR
Q2400 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q2401 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q2410 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q2411 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q2412 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q2413 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q2414 8-729-422-27 TRANSISTOR 2SD601A-Q
Q2418 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q2419 8-729-120-28 TRANSISTOR 2SC1623-L5L6
RESISTOR
R2401 1-216-845-11 METAL CHIP 100K 5% 1/10W
R2402 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2403 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R2404 1-216-835-11 METAL CHIP 15K 5% 1/10W
R2405 1-218-895-11 METAL CHIP 100K 0.50% 1/10W
R2406 1-218-714-11 METAL CHIP 8.2K 0.50% 1/10W
R2407 1-216-835-11 METAL CHIP 15K 5% 1/10W
R2408 1-218-868-11 METAL CHIP 7.5K 0.50% 1/10W
R2409 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2410 1-216-835-11 METAL CHIP 15K 5% 1/10W
R2411 1-216-841-11 METAL CHIP 47K 5% 1/10W
R2412 1-218-868-11 METAL CHIP 7.5K 0.50% 1/10W
R2413 1-216-841-11 METAL CHIP 47K 5% 1/10W
R2414 1-216-835-11 METAL CHIP 15K 5% 1/10W
R2415 1-220-397-11 METAL CHIP 4.7M 5% 1/10W
R2416 1-216-837-11 METAL CHIP 22K 5% 1/10W
R2417 1-216-837-11 METAL CHIP 22K 5% 1/10W
R2418 1-216-809-11 METAL CHIP 100 5% 1/10W
R2419 1-216-809-11 METAL CHIP 100 5% 1/10W
R2420 1-216-837-11 METAL CHIP 22K 5% 1/10W
R2421 1-216-837-11 METAL CHIP 22K 5% 1/10W
R2422 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2423 1-216-840-11 METAL CHIP 39K 5% 1/10W
R2424 1-216-840-11 METAL CHIP 39K 5% 1/10W
R2425 1-216-840-11 METAL CHIP 39K 5% 1/10W
R2426 1-216-817-11 METAL CHIP 470 5% 1/10W
R2427 1-216-817-11 METAL CHIP 470 5% 1/10W
R2428 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R2429 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R2430 1-216-809-11 METAL CHIP 100 5% 1/10W
