Sony TRINITRON KV-21FA310 - Page 79

79
KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
HR
* A-1415-629-A HR (VAR) BOARD, MOUNTED
(KV-21FA310 only)
CAPACITOR
C3001 1-104-665-11 ELECT 100µF 20% 25V
CONNECTOR
* CN3001 1-564-521-11 PLUG, CONNECTOR 6P
DIODE
D3001 8-719-109-89 DIODE RD5.6ESB2
D3002 8-719-057-09 DIODE LNJ801LPDJA
IC
IC3001 8-742-211-20 HYB IC SBX3071-71
RESISTOR
R3001 1-249-417-11 CARBON 1K 5% 1/4W
R3014 1-247-807-31 CARBON 100 5% 1/4W
SWITCH
S3006 1-786-338-12 SWITCH, TACTILE
HB
* A-1415-580-A HB (VAR) BOARD, MOUNTED
(ALL EXCEPT KV-21FA310LN/21FA310LS/21FM120)
* A-1415-692-A HB (VAR) BOARD, MOUNTED
(KV-21FM120 ONLY)
CAPACITOR
C2001 1-104-665-11 ELECT 100µF 20% 25V
C2234 1-126-960-11 ELECT 1µF 20% 50V
C2235 1-126-960-11 ELECT 1µF 20% 50V
C2401 1-126-965-91 ELECT 22µF 20% 50V
C2402 1-126-965-91 ELECT 22µF 20% 50V
CONNECTOR
* CN2402 1-564-507-11 PLUG, CONNECTOR 4P
DIODE
D2001 8-719-109-89 DIODE RD5.6ESB2
D2002 8-719-070-80 DIODE LNK0120022G
D2003 8-719-109-89 DIODE RD5.6ESB2
D2004 8-719-109-89 DIODE RD5.6ESB2
D2005 8-719-109-89 DIODE RD5.6ESB2
D2233 8-719-108-12 DIODE RD9.1EW
D2235 8-719-108-12 DIODE RD9.1EW
D2236 8-719-108-12 DIODE RD9.1EW
FERRITE BEAD
FB2001 1-410-397-21 FERRITE 1.1µH
FB2002 1-410-397-21 FERRITE 1.1µH
FB2003 1-410-397-21 FERRITE 1.1µH
FB2004 1-410-397-21 FERRITE 1.1µH
IC
IC2001 8-742-212-20 HYB IC SBX3081-71
JACK
J2231 1-794-048-11 JACK, PIN 3P
(ALL EXCEPT KV-21FA310LN/21FA310LS/21FM120)
J2231 1-580-441-41 JACK, PIN 2P
(KV-21FM120 ONLY)
J2401 1-568-267-21 JACK
RESISTOR
R2004 1-249-417-11 CARBON 1K 5% 1/4W
R2007 1-247-807-31 CARBON 100 5% 1/4W
R2008 1-249-427-11 CARBON 6.8K 5% 1/4W
R2009 1-249-421-11 CARBON 2.2K 5% 1/4W
R2010 1-249-416-11 CARBON 820 5% 1/4W
R2011 1-249-415-11 CARBON 680 5% 1/4W
R2201 1-249-419-11 CARBON 1.5K 5% 1/4W
R2202 1-249-421-11 CARBON 2.2K 5% 1/4W
R2203 1-249-427-11 CARBON 6.8K 5% 1/4W
R2234 1-247-804-11 CARBON 75 5% 1/4W
HB
HR
