Sony TRINITRON KV-DA29M81 - Page 88

– 98 –
KV-DA29M81
RM-W105
IC6800 1 1.3
23.0
31.5
40
5 3.1
6 2.8
7 8.6
8 12.0
IC6801 1 1.0
680.0mVp-p
PA L
1
1.008Vp-p
NTSC
1
2 14.0
3 -14.0
30.0Vp-p
2
4 -15.0
5 (0.2)[*]
6 14.0
7 1.0
1.740Vp-p
3
DY1 V+ 0.1
64.00Vp-p
PA L
4
65.60Vp-p
NTSC
4
Ref Pin No. Voltage[v]Ref Pin No. Voltage[v]
IC6600 1 -11.0
2 -11.0
3 -11.0
4 -11.0
5 -13.0
6 -13.0
7 -8.0
86.4
9 -13.0
10 -2.7
11 -14.0
12 -8.0
13 0
14 132.0
15 122.0
16 127.0
17 0
18 253.0
IC6602 1 0
20
3 (*)[5.0]
4 6.9
5 5.0
60
70
IC6604 I 14.0
G0
O 12.0
IC6607 1 0.1
20
30
40
5*
196.0mVp-p
PA L
8
204.0mVp-p
NTSC
8
6 9.9
70
80
IC6608 1 0
20
3 18.0
4 2.0
5 2.0
6 2.0
7 2.0
8 3.0
9 5.0
10 18.0
11 5.0
12 0
13 0.1
14 18.0
D BOARD VOLTAGE LIST
Ref Pin No. Voltage[v]
V- 0
512.0mVp-p
PA L
5
560.0mVp-p
NTSC
5
H- 135.0
284.0Vp-p
PA L
6
318.0Vp-p
NTSC
6
H+ *
374.0Vp-p
PA L
7
370.0Vp-p
NTSC
7
PH6601 1 5.0
2 3.8
3 0.1
4 0.4
PH6602 1 12.0
2 11.0
3 -13.0
4 -12.0*
Q6100 S 0
G 1.0
D 0.2
Q6600 S 0.1
G 0.1
D 0.2
Q6601 B *
C 12.0
E-0
Ref Pin No. Voltage[v]
Q6603 S -13.0
G -8.0
D 122.0
Q6605 B 0.8
C (0.1)[*]
E0.1
Q6606 B 0
C5.0
E0
Q6607 B *
C*
E 5.0
Q6608 B 0.7
C0
E0
Q6609 B 5.0
C0
E5.0
Q6801 S 0
G 8.6
D 31.0
Q6804 B 134.5
C0.1
E 135.0
Q6807 B 5.0
C (0)[4.2]
E4.3
Q6809 B 0
C0
E0
Q6810 B -0.5
C 14.0
E 0.1
Q6811 B (1.0)[0.4]
C0
E (0.4)[1.0]
Q6812 B 0.7
C 12.0
E1.0
Q6813 B 0.7
C0
E1.0
Q6814 B 0.1
C0
E0
Q6816 B 5.2
C0
E (*)[5.1]
Q6817 B 5.0
C (*)[12.0]
E 5.0
Q6818 S 0
G 5.0
D0.6
Q6819 B 0.6
C (*)[0]
E0
