Adjustment Using the Menus / Troubleshooting
29
REMOTE menu
USER SERVICE menu
The USER SERVICE menu is provided for any
adjustments or settings other than those listed above.
To access the USER SERVICE menu, press and hold the
MENU/EXIT button while the menu is displayed, until
the USER SERVICE menu shown below appears.
Troubleshooting
This section may help you isolate the cause of a problem
and as a result, eliminate the need to contact technical
support.
• The display is colored green or purple t Select the
correct input by pressing one of the buttons related to
input.
• The signal input through the RGB/COMPONENT
input connectors does not appear on the screen t
Set RGB SYSTEM on the USER CONFIG menu
appropriately according to type of input signal.
Submenu Setting
PARALLEL REMOTE... The REMOTE menu is used to
assign the functions to the pins of
the PARALLEL REMOTE
terminal.
Pin 1 to 4 and pin 6 to 8 can be
used. The following lists the
functions you can assign to the
pins.
• – – (No function is assigned.)
•LINE A
•LINE B
• RGB/COMP
•OPTION 1
•OPTION 2
•TALLY
• UNDERSCAN
• OVERSCAN
•DEGAUSS
Note
If you use the PARALLEL
REMOTE function, you need to
connect cables.
For more details, see page 31.
SERIAL REMOTE Select one out of following three
modes.
RMT OFF:
You can adjust settings and controls
by the buttons and controls on the
control panel.
The RS-232C connector does not
function.
RMT ON:
You can adjust settings and controls
through the RS-232C connector.
Buttons and controls on the control
panel, except the menu operation
ones, do not function.
RMT & LCL:
You can adjust settings and controls
both through the RS-232C
connector and the control panel
buttons.
Controls on the control panel do not
function.
Submenu Setting
FORMAT DISP Determines whether the format of a
input signal is displayed on the
screen or not.
ON: The format is always
displayed.
AUTO: The format is displayed
for about 10 seconds when the
input of the signal begins.
OFF: The format is always
hidden.
COMP LEVEL Select the component level from
among three modes.
SMPTE: 100/0/100/0 signal
BETA 7.5: 100/7.5/75/7.5 signal
BETA 0: 100/0/75/0 signal
NTSC SETUP Select the NTSC setup level from
two modes.
The 7.5 setup level is used mainly
in North America. The 0 setup level
is used mainly in Japan.
DEGAUSS DELAY Sets the delay time for auto
degaussing to start working after
the power is turned on. The delay
time can be set within 0 to 99
seconds.
USER COLOR TEMP The value of adjustment in this
menu works only when USER is
selected in the COLOR TEMP
menu.
• ADJUST GAIN...: Adjusts the
color balance (GAIN).
• ADJUST BIAS...: Adjusts the
color balance (BIAS).
• COPY FROM: If you select
D65, D56 or D93 with the
M/+ or m/– button, the white
balance data of the selected
color temperature will be
copied to USER.
SUB CONTROL You can finely adjust the controls
on the front panel. CONTRAST,
PHASE, CHROMA and BRIGHT
controls have clicks at the center of
their adjustment range. You can
adjust the setting of the click
position with this feature.
Submenu Setting
