67
Specifications
Miscellaneous
Specifications
Power requirements
100 to 240 V AC, 50/60 Hz
Input current 1.7 to 1.0 A
Operating temperatures
5 °C to 35 °C (41 °F to 95 °F)
Operating humidity
20% to 80% (no condensation)
Operating pressure
700 hPa to 1,060 hPa
Storage and transport temperature
−20 °C to +60 °C (−4 °F to +140 °F)
Storage and transport humidity
20% to 80% (no condensation)
Storage and transport pressure
700 hPa to 1,060 hPa
Dimensions Approx. 212 × 98 × 398 mm (w × d × h)
Weight Approx. 5.7 kg (printer only)
Printing system Dye transfer sublimation thermal printing
Thermal head 423 dpi
Gradations 8-bit (256-level) processing each for
yellow, magenta, and cyan
Picture elements
Full-image print using UPC-21S/
UPC-24SA: 1,600 × 1,260 dots
Full-image print using UPC-21L/
UPC-24LA: 2,132 × 1,600 dots
Printing time UPC-21S
Approx. 19 seconds (high speed print)
UPC-21L
Approx. 29 seconds (high speed print)
UPC-24SA
Approx. 25 seconds (high speed print)
UPC-24LA
Approx. 36 seconds (high speed print)
TV system Select from NTSC/PAL signal system
(using NTSC/PAL switch)
HDTV IN/OUT signals
1080i/59.94i, 1080/50i (2:1 interlace)
720/59.94p, 720/50p (progressive)
Input connectors
RGB/YPbPr (BNC × 3):
0.7 Vp-p
SYNC ON G: 0.3 Vp-p, sync negative
SYNC (BNC × 1)
0.3 to 4 Vp-p, sync negative
S VIDEO (4-pin mini-DIN × 1):
Y: 1 Vp-p, sync negative
C: 0.286 Vp-p (NTSC), 0.3 Vp-p
(PAL)
VIDEO (BNC × 1) :
1 Vp-p, sync negative
AC IN (for power input)
Output connectors
RGB/YPbPr (BNC × 3):
0.7 Vp-p
SYNC ON G: 0.3 Vp-p, sync negative
SYNC (BNC × 1)
0.3 to 4 Vp-p, sync negative
S VIDEO (4-pin mini-DIN × 1):
Y: 1 Vp-p, sync negative
C: 0.286 Vp-p (NTSC), 0.3 Vp-p
(PAL)
VIDEO (BNC × 1):
1 Vp-p, sync negative
Controls connectors
REMOTE 1: special mini jack × 1
For RM-5500 Remote Control Unit
(not supplied)
REMOTE 2 (automatic printing
connector): Stereo mini jack: × 1
For optional RM-91 Remote Control
Unit or FS-24 Foot Switch
RS-232C (Computer control interface):
D-SUB 25-pin connector × 1
Output: 5-kilohm load
Typical ± 8 V
Input: 5-kilohm load
High level 5 to 15 V
Low level −5 to −15 V
Supplied accessories
Paper feed tray (1)
Stopper (1)
Before Using this Printer (1)
CD-ROM (instructions for use) (1)
Thermal head cleaning cartridge (1)
Optional accessories
Color Printing Pack UPC-21S: 240 sheets
(80 sheets × 3)
Color Printing Pack UPC-21L: 200
sheets (50 sheets × 4)
Laminate Color Printing Pack
UPC-24SA: 180 sheets (60 sheets × 3)
Laminate Color Printing Pack
UPC-24LA: 160 sheets (40 sheets × 4)
FS-24 Foot Switch
RM-91 Remote Control Unit
RM-5500 Remote Control Unit
