Sony UP-895 - Major Parts Removal Procedures

2-2
UP-895/(E)
2-3. Removal of Major Parts
2-3-1. Removal of Mechanical Block
1. Remove the top cover. (Refer to Section 2-2.)
3
Step screw
3
Step screw
Lock arm
4
Door panel
Claws
Claws
2
1
6
Power switch rod
5
Rod stopper
1
CN14
1
CN1
2
Screw (BVTT 3x6)
2
Screws (BVTT 3x6)
4
Front panel
3
Claws
3
Claws
3
Mechanical block
1
CN7
1
CN2
1
CN8
1
CN13
2
Screws (BVTT 3x6)
Be careful not to slacken
the harness when installing
the mechanical block.
1
CN3
1
CN9
