Sony UP-895 - Removal of MA-99 Board; Removal of Switching Regulator

2-3
UP-895/(E)
2-3-2. Removal of MA-99 Board
1. Remove the top cover. (Refer to Section 2-2.)
4
CN7
6
MA-99 board
4
CN2
4
CN12
5
Tapping screws (M3)
5
Tapping
screws (M3)
4
CN14
4
CN1
4
CN8
4
CN13
4
CN3
4
CN9
4
Screws
(PS 3x6)
4
Screws (PS 3x6)
1
Tapping
screw (M3)
1
Tapping screw
(M3)
3
CN201
6
Switching
regulator
2
Sheeld plate
1
Tapping
screws
(M3)
3
Rear panel
2
Screw
(BTP 3x8)
2-3-3. Removal of Switching Regulator
1. Remove the top cover. (Refer to Section 2-2.)
2. Remove the front panel, door panel and power switch
rod. (Refer to Section 2-3-1.)
3. Remove the MA-99 board. (Refer to Section 2-3-2.)
