System Configuration Example
The following is a configuration example for use with UWP-D series devices.
Sample configuration for ENG (Electronic News Gathering) or EFP (Electronic Field Production) with a
camcorder
For URX-P40 portable diversity tuner
For URX-P41D portable diversity tuner
Portable diversity tuner (URX-P40)
(with shoe mount adaptor attached or XLR-BMP cable connection)
Body-pack
transmitter
(UTX-B40)
XDCAM EX/HDV camcorder
(HXR-NX3, etc.)
or
1 XLR-BMP conversion output cable (supplied)
Hand-held
microphone
(UTX-M40)
or
Plug-on
transmitter
(UTX-P40)
Portable diversity tuner (URX-P41D)
(shoe mount adaptor attached or XLR-BMP cable connection)
Body-pack
transmitter
(UTX-B40)
XDCAM EX/HDV camcorder
(HXR-NX3, etc.)
1 XLR-BMP conversion output cable (supplied)
Hand-held
microphone
(UTX-M40)
Plug-on
transmitter
(UTX-P40)
Up to two devices
