The Connection/Power Menu
Adjustments and Settings Using a Menu
The Connection/Power Menu
The Connection/Power menu is used for setting for the connections and power.
Items Item descriptions
LAN Settings
IP Address
Setup
*9
Auto (DHCP): The IP address is assigned automatically from the
DHCP server such as a router.
Manual: To specify the IP Address manually.
WLAN Settings
*10
WLAN
Connection
*8
On/Off: Set the wireless output of the USB wireless LAN module (not
supplied) to On/Off.
WLAN
Network
*14
Access Pt. (Auto)/Access Pt. (Manual)/Client
*11
: Changes modes for
WLAN.
*12
Network Presentation
Connection
CODE
On/Off: This is the presentation function via the network. It controls
the connection using the displayed number (CODE) on the right bottom
of the screen. During the image transmission, using the ENTER key on
the remote commander makes Connection CODE display again.
HDBaseT setting Sets the function of the HDBaseT/LAN connector.
HDBaseT/LAN
connector
HDBaseT: Connecting the HDBaseT transmitter and the LAN cable
enables transmitting the signal of the Video, Audio, Ethernet, and
RS-232C.
LAN: Connecting the LAN cable for Ethernet directly enables
connecting to the network.
(Use when connecting the cable directly without the HDBaseT
transmitter.)
RS-232C setting Via HDBaseT: You can connect this unit to the RS-232C connector via
the HDBaseT transmitter. (Baud rate: 9600bps)
RS-232C connector: Use when connecting to the RS-232C connector
of this unit directly.
Dynamic Range
*16
Sets the image input level of the INPUT B/C/D connector.
*17
Auto: Distinguishes the image input level automatically.
Limited: Set when the image input level is 16-235.
Full: Set when the image input level is 0-255.
Input-A Signal Sel.
Auto/Computer/Video GBR/Component:
When set to “Auto,” selects
the type of video signal input automatically when “Input-A” is selected.
*1
ECO
Lamp Mode
High/Standard/Low/Auto
*5 *15
: When set to “High,” the image
becomes brighter, and power consumption becomes higher. When set to
“Low,” power consumption is minimized; however, the image will be
darker. When set to “Auto,” brightness is adjusted automatically
according to image content. Dark images are projected with brightness
adjusted, leading to energy-saving. Bright images are projected
brightly, without adjusting brightness.
Constant
Brightness
On/Off: Available when the lamp mode is set to High. Outputs light at
a certain brightness.
*13
