6
Location and Function of Controls
f VIDEO (VIDEO IN)
Video: Video input connector (VIDEO)
Audio: Audio input connector
(L (MONO) AUDIO/R)
The audio inputs of S VIDEO and VIDEO are
shared.
Output (page 16)
g OUTPUT
Video: Monitor output connector
(MONITOR)
Audio: Audio output connector
(AUDIO)
• This connector outputs the projected image
only when INPUT A is used.
• When the speaker setting is set to “Always
On” and the lamp is turned off, the audio of
INPUT A and the microphone are enabled.
Others
h RS-232C connector (RS-232C)
RS-232C compatible control connector.
Connects the computer’s RS-232C
connector and the RS-232C cross cables.
i AC IN (∼) socket
Connects the supplied AC power cord.
j USB connector (Type A) ( )
(page 11)
k USB connector (Type B) ( )
(page 51)
l Microphone input ( )
Note
Notes
