Sony VPL-HS20 - Extension Board and Extension Connectors

1-11
VPL-HS20
SR connector assembly (12P)
ZH connector assembly (7P)
ZH connector assembly (8P)
ZH connector assembly (10P)
ZH connector assembly (9P)
Flat connector assembly (32P) x3
SR connector assembly (5P)
SR connector assembly (3P)
PH connectors assembly (3P) x2
ZH connector assembly B (3P)
SR connector assembly (2P)
ZH connector assembly (4P)
SR connector assembly (4P)
X kit assembly (A-1606-452-A)
Flat connector assembly (50P) x8
X1 board
X3 board
X5 board
X7 board
X6 board
X2 board X2 board
X3 board
1-3-15. Extension Board and Extension Connectors
