Gamma memory is actualized through Gamma mode
functions’offsetting the output values to the Contrast and
Brightness devices.
When the power plug is connected to the power line
(Standby status), all data inside the internal ROM are
written into the NVM (Nonvolatile Memory). When the
power is turned to on, required data for the current picture,
such as status memory data, etc., are selected, and they are
written into the internal RAM.
When adjustment is carried out, adjustment data are
written into the NVM automatically (items on the user
mode) or by the trigger of memory operation (items on the
service mode and special service mode), then stored them.
Adjustable items (W/B and Device Adjust) of the service
mode and special service mode are memorized into the
NVM by the memory operation. At the same time, the
factory preset (adjusted) data are all eliminated from the
memory.
1-5. Memory
Memory structure consists of the following five memory
blocks.
1. Set memory
2. Status memory
3. Chroma memory
4. W/B memory
5. Channel memory
6. Image Flip memory
7. Picture memory
CPU internal ROM : 384 kbyte Flash Memory
CPU internal ROM : 30 kbyte
External NVM memory : 16 kbyte EEPROM
NT358/443/BW60
PAL/PAL-M/N/
SECAM/BW50
15k RGB
Component (15k)
Two times speed
Component
HDTV (YPbPr)
NT358/443/BW60
PAL/PAL-M/N/
SECAM/BW50
15k RGB
Component (15k)
Two times speed
Component
HDTV (YPbPr)
HDTV (GBR)
(Include two times speed)
HDTV (GBR)
(Include two times speed)
Computer
High
Low
Middle
High
Low
Middle
Custom1
Custom3
Custom2
Custom1
Custom3
Custom2
Others
Computer
Custom1
Custom3
Custom2
Custom1
Custom3
Custom2
Others
W/B
Memory
High
Low
Middle
Custom1
Custom3
Custom2
High
Low
Middle
High
Low
Middle
No.02
No.03
No.04
...
No.99
No.01
Status
Memory
No.01
No.02
No.03
No.04
...
No.99
Status
Memory
Set Memory Set Memory Set Memory
Status Memory
Chroma Memory
Input-A
Preset
No.03
No.04
...
No.99
Component
No.101
...
No.120
Input-A
User
No.03
No.04
...
No.99
Digital
Preset
No.03
No.04
...
No.99
HDMI
No.121
...
No.140
Digital
User
No.53
No.69
...
MS
Chroma
Memory
Chroma
Memory
W/B
Memory
W/B
Memory
