Sony VPL-HS20 - Page 53

4-9
VPL-HS20
Optics-1
No. Part No. SP Description
301 A-1606-420-A s PRIMS BLOCK ASSY
302 A-1606-419-A s OPT UNIT ASSY
303 A-1606-426-A s PANEL (R) ASSY, OUT-POLARIZER
304 A-1606-427-A s PANEL (G) ASSY, OUT-POLARIZER
305 A-1606-428-A s PANEL (B) ASSY, OUT-POLARIZER
306 A-1606-421-A s PROJECTION LENS ASSY
307 ! 1-576-523-11 s THERMOSTAT
308 ! 1-763-695-12 s FAN, DC
309 3-681-360-11 s SCREW, SPRING WASHER
310 4-091-805-01 o BRACKET FAN (R)
311 4-091-811-01 o DUCT LAMP (UP)
312 4-091-812-11 o DUCT LAMP (LOW)
313 4-091-814-02 o HOUSING, LAMP
314 4-382-854-11 s SCREW +PSW M3X10 (EP-EF/ZNBK/CM2)
315 4-099-471-01 s PLATE, WV-FILM (1)
315 4-099-472-01 s PLATE, WV-FILM (2)
316 4-099-471-11 s PLATE, WV-FILM (1) WV-FILM PLATE to be used varies depending on the combination with the panels.
316 4-099-472-11 s PLATE, WV-FILM (2) Refer to 1-3-10. Disassembly for the combination with the panels.
317 4-099-471-21 s PLATE, WV-FILM (1)
317 4-099-472-21 s PLATE, WV-FILM (2)
Screws/Washers
7-621-775-40 s SCREW +B 2.6X8 (EP-EF/ZNBK/CM2)
7-682-547-04 s SCREW +B 3X6
7-682-548-04 s SCREW +B 3X8
7-682-553-09 s SCREW +B 3X20
7-685-645-79 s SCREW +BVTP 3X6 (EP-EF/ZNBK/CM2)
7-621-772-10 s SCREW +B 2X4
