2-17
VPL-HS60/HS51A
Adjustment
The adjustment procedures of “1. High”, “2. Middle” and
“3. Low” modes are the same as those in “2-4-1.
Computer”.
m
. Use the two times speed Component or two times speed
VideoGBR signal as the input signal according to step 3
in Preparation.
. Use the reference color of High, Middle and Low same
as that in “2-4-1. Computer”.
3. Input WXGA 80 IRE Window white (3 colors: RGB)
to INPUT-A and adjust the GAIN of colors other than
R of white balance so that the chromaticity (x80 and
y80) is within specification.
4. Repeat steps 2 and 3, and adjust each GAIN and BIAS
of RGB so that x and y are within the following
specification.
x: 0.313 ± 0.002
y: 0.329 ± 0.003
5. Save the adjustment values.
4. Custom1/2/3
1. Copy the values adjusted in “1. High”, “2. Middle”
and “3. Low” as follows.
Custom1: High
Custom2: Middle
Custom3: Low
2. Save the adjustment values.
2-4-2. Video
Preparation
1. Set the unit from the menu as follows.
Picture Mode: Cinema
Adjust Picture
Contrast: 80
Brightness: 50
Color: 50
Hue: 50
Sharpness: 50
Black Level Adj.: OFF
Gamma Correction: OFF
Cinema Black Pro:
Iris Control: OFF
Lamp Control: Low
2. Set each mode of “Color Temp:” as follows.
Gain: 150
Bias: 127
3. Set INPUT-A Signal Sel. to “Component” or “Video
GBR”.
