– 24 –
SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Ref. No. Part No. Description Remark
When indicating parts by reference
number, please include the board.
• Abbreviation
CND : Canadian
IT : Italian
EA : Saudi Arabia
EE : East European
E : Radio Section (ST/MONO)
5E, 6E : Radio Section (DX/LOCAL)
A-3021-052-A MAIN BOARD, COMPLETE (CND)
A-3021-053-A MAIN BOARD, COMPLETE (FX373: AEP, E)
A-3021-054-A MAIN BOARD, COMPLETE (FX373: IT, EA)
A-3021-055-A MAIN BOARD, COMPLETE (FX373: EE)
A-3021-056-A MAIN BOARD, COMPLETE (FX373: 5E)
A-3021-058-A MAIN BOARD, COMPLETE (US)
A-3021-059-A MAIN BOARD, COMPLETE (FX375: AEP, E)
A-3021-060-A MAIN BOARD, COMPLETE (FX375: EE)
A-3021-061-A MAIN BOARD, COMPLETE (FX375: EA)
A-3021-062-A MAIN BOARD, COMPLETE (FX375: 5E, 6E)
*********************
3-019-862-01 TERMINAL (+), BATTERY
3-022-293-01 KNOB, TUNING
3-022-294-01 POINTER
3-022-579-01 TERMINAL, –
< CAPACITOR >
C1 1-163-083-00 CERAMIC CHIP 1PF 50V
(EXCEPT IT, EA)
C1 1-163-086-00 CERAMIC CHIP 3PF 50V
(IT, EA)
C2 1-163-099-00 CERAMIC CHIP 18PF 5% 50V
(EXCEPT IT, EA, EE)
C2 1-163-101-00 CERAMIC CHIP 22PF 5% 50V
(IT, EA)
C2 1-163-087-00 CERAMIC CHIP 4PF 50V (EE)
C3 1-163-100-00 CERAMIC CHIP 20PF 5% 50V
(EXCEPT IT, EA, EE)
C3 1-163-103-00 CERAMIC CHIP 27PF 5% 50V
(IT, EA)
C3 1-163-089-00 CERAMIC CHIP 6PF 50V (EE)
C4 1-163-089-00 CERAMIC CHIP 6PF 50V
(US, CND, 5E, 6E)
C4 1-163-091-00 CERAMIC CHIP 8PF 50V
(AEP, E, EE)
C4 1-164-275-91 CERAMIC CHIP 9PF 5% 50V
(IT, EA)
C5 1-162-937-11 CERAMIC CHIP 6PF 0.5PF 50V
C6 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C7 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C8 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C9 1-115-156-11 CERAMIC CHIP 1uF 10V
C10 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C11 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C12 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C14 1-126-163-11 ELECT 4.7uF 20% 50V
C15 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C16 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C17 1-126-154-11 ELECT 47uF 20% 6.3V
C18 1-163-022-00 CERAMIC CHIP 0.012uF 10% 50V
(EXCEPT US, CND, 5E, 6E)
C18 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
(US, CND, 5E, 6E)
C19 1-163-022-00 CERAMIC CHIP 0.012uF 10% 50V
(EXCEPT US, CND, 5E, 6E)
C19 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
(US, CND, 5E, 6E)
C20 1-115-156-11 CERAMIC CHIP 1uF 10V
C21 1-115-156-11 CERAMIC CHIP 1uF 10V
C22 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C23 1-115-156-11 CERAMIC CHIP 1uF 10V
C24 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C26 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C101 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C102 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C103 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C104 1-126-157-11 ELECT 10uF 20% 16V
C105 1-115-156-11 CERAMIC CHIP 1uF 10V
(FX373)
C106 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C107 1-115-156-11 CERAMIC CHIP 1uF 10V
C108 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C131 1-115-156-11 CERAMIC CHIP 1uF 10V
(FX375)
C132 1-164-505-11 CERAMIC CHIP 2.2uF 16V
(FX375)
C133 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
(FX375)
C134 1-115-156-11 CERAMIC CHIP 1uF 10V
(FX375)
C201 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C202 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C203 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C204 1-126-157-11 ELECT 10uF 20% 16V
C205 1-115-156-11 CERAMIC CHIP 1uF 10V
(FX373)
MAIN
To Next Page
