WM-GX410
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
MAIN
C358 1-131-862-91 TANTAL. CHIP 47uF 20% 4V
C374 1-115-156-11 CERAMIC CHIP 1uF 10V
C401 1-100-539-91 TANTAL. CHIP 47uF 20% 6.3V
C403 1-100-539-91 TANTAL. CHIP 47uF 20% 6.3V
C405 1-100-539-91 TANTAL. CHIP 47uF 20% 6.3V
C406 1-109-847-11 TANTAL. CHIP 0.47uF 20% 16V
C407 1-117-887-91 TANTAL. CHIP 220uF 20% 6.3V
C408 1-135-834-91 CERAMIC CHIP 2.2uF 6.3V
C409 1-135-834-91 CERAMIC CHIP 2.2uF 6.3V
C410 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C413 1-135-834-91 CERAMIC CHIP 2.2uF 6.3V
C414 1-126-518-11 ELECT 470uF 20% 4V
C415 1-127-569-91 TANTAL. CHIP 100uF 20% 4V
C416 1-127-569-91 TANTAL. CHIP 100uF 20% 4V
C417 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C418 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C419 1-113-690-11 ELECT CHIP 220uF 20% 4V
C420 1-115-156-11 CERAMIC CHIP 1uF 10V
C485 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C486 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C487 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C488 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C489 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C490 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C491 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C501 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C502 1-100-539-91 TANTAL. CHIP 47uF 20% 6.3V
C503 1-100-539-91 TANTAL. CHIP 47uF 20% 6.3V
C504 1-126-518-11 ELECT 470uF 20% 4V
C507 1-100-539-91 TANTAL. CHIP 47uF 20% 6.3V
C529 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C601 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C602 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C603 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C604 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C605 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C606 1-135-149-21 TANTAL. CHIP 2.2uF 20% 6.3V
C607 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C608 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C609 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C612 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C613 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C614 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C903 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C905 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C906 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C907 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C908 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C909 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C911 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C912 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C913 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C915 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C920 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
* CN301 1-778-178-21 CONNECTOR, FFC/FPC (ZIF) 30P
CN303 1-573-349-21 CONNECTOR, FFC/FPC 9P
< TRIMMER >
CT1 1-141-422-11 CAP, ADJ 10PF (AM TRACKING)
< DIODE >
D1 8-719-076-70 DIODE KV1520TL
D2 8-719-080-77 DIODE MA2S357 (E) -(TX).SO
D4 8-719-080-77 DIODE MA2S357 (E) -(TX).SO
D5 1-216-864-11 SHORT CHIP 0 (AEP, 9E, EA, CH, JEW)
D5 6-500-174-01 DIODE MA2SP0100LSO (CND, 5E)
D13 6-500-944-01 DIODE MA3SE02
D406 8-719-988-61 DIODE 1SS355TE-17
D501 8-719-049-09 DIODE 1SS367-T3SONY
D502 8-719-049-09 DIODE 1SS367-T3SONY
< FERRITE BEAD >
FB1 1-500-329-21 INDUCTOR, FERRITE BEAD
FB101 1-414-760-21 FERRITE, EMI (SMD) (1608)
FB201 1-414-760-21 FERRITE, EMI (SMD) (1608)
FB301 1-414-760-21 FERRITE, EMI (SMD) (1608)
FB302 1-414-760-21 FERRITE, EMI (SMD) (1608)
FB303 1-414-760-21 FERRITE, EMI (SMD) (1608)
FB305 1-414-760-21 FERRITE, EMI (SMD) (1608)
FB306 1-414-760-21 FERRITE, EMI (SMD) (1608)
FB401 1-414-760-21 FERRITE, EMI (SMD) (1608)
< IC >
IC1 8-752-073-35 IC CXA1960Q
IC301 8-759-638-51 IC LB1979VL-TLM-E
IC302 8-752-089-40 IC CXA2500N-T4
IC401 6-705-969-01 IC LM4873MTXNOPB
< JUMPER RESISTOR >
J1 1-216-864-11 SHORT CHIP 0
J2 1-216-864-11 SHORT CHIP 0
J3 1-216-864-11 SHORT CHIP 0
J4 1-216-864-11 SHORT CHIP 0
J9 1-218-990-11 SHORT CHIP 0
< JACK >
J302 1-766-847-51 JACK (MIC(PLG IN POWER))
J401 1-766-847-22 JACK (i)
J501 1-794-615-11 JACK, DC (POLARITY UNIFIED TYPE) (DC IN 3V)
< COIL >
L3 1-456-666-11 BAR ANTENNA (FERRITE-ROD) (AM TRACKING)
L4 1-424-730-21 COIL (FM RF) (FM TRACKING)
L6 1-469-781-21 INDUCTOR 30nH
L7 1-419-984-11 COIL, VARIABLE (OSC)
(AM FREQUENCY COVEREGE)
L900 1-469-607-21 INDUCTOR 330nH
< TRANSISTOR >
Q2 8-729-014-12 TRANSISTOR RN1311-TE85L
Q3 8-729-423-52 TRANSISTOR 2SC3931-C
Q101 8-729-028-27 TRANSISTOR 2SK2009 (TE85L)
Q104 8-729-028-27 TRANSISTOR 2SK2009 (TE85L)
Q105 8-729-028-27 TRANSISTOR 2SK2009 (TE85L)
Q111 8-729-028-27 TRANSISTOR 2SK2009 (TE85L)
