26
WM-GX410
SECTION 6
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
•SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference
number, please include the board.
• Abbreviation
CND : Canadian
EA : Saudi Arabia
CH : Chinese
JEW : Tourist
5E : Indication of country of origin
9E : No Indication of country of origin
* A-4542-821-A MAIN BOARD, COMPLETE (9E, EA, CH, JEW)
* A-4542-822-A MAIN BOARD, COMPLETE (CND, 5E)
* A-4547-098-A MAIN BOARD, COMPLETE (AEP)
******************
3-237-149-11 TERMINAL (-), BATTERY
3-237-150-11 TERMINAL (+), BATTERY
< CAPACITOR >
C4 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C5 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C6 1-115-156-11 CERAMIC CHIP 1uF 10V
C7 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C8 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C9 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C11 1-115-156-11 CERAMIC CHIP 1uF 10V
C12 1-135-151-21 TANTAL. CHIP 4.7uF 20% 4V
C16 1-135-151-21 TANTAL. CHIP 4.7uF 20% 4V
C17 1-135-201-11 TANTAL. CHIP 10uF 20% 4V
C18 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C19 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C20 1-115-156-11 CERAMIC CHIP 1uF 10V
C21 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C23 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C24 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C25 1-162-909-11 CERAMIC CHIP 4PF 0.25PF 50V
C26 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C28 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C29 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C30 1-135-201-11 TANTAL. CHIP 10uF 20% 4V
C31 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C32 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C34 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C35 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
C39 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C40 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C43 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C49 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C53 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C55 1-164-843-11 CERAMIC CHIP 3PF 0.25PF 50V
C56 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C57 1-164-843-11 CERAMIC CHIP 3PF 0.25PF 50V
C60 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
C61 1-162-957-11 CERAMIC CHIP 220PF 5% 50V
C62 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C71 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C80 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C84 1-218-990-11 SHORT CHIP 0
C86 1-164-918-11 CERAMIC CHIP 100PF 5% 16V
C89 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C101 1-135-834-91 CERAMIC CHIP 2.2uF 6.3V
C103 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C104 1-131-862-91 TANTAL. CHIP 47uF 20% 4V
C105 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C111 1-115-156-11 CERAMIC CHIP 1uF 10V
C151 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C152 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C154 1-115-156-11 CERAMIC CHIP 1uF 10V
C155 1-115-156-11 CERAMIC CHIP 1uF 10V
C156 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C187 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C190 1-135-834-91 CERAMIC CHIP 2.2uF 6.3V
C201 1-135-834-91 CERAMIC CHIP 2.2uF 6.3V
C203 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C204 1-131-862-91 TANTAL. CHIP 47uF 20% 4V
C205 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C221 1-115-156-11 CERAMIC CHIP 1uF 10V
C251 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C252 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C254 1-115-156-11 CERAMIC CHIP 1uF 10V
C255 1-115-156-11 CERAMIC CHIP 1uF 10V
C256 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C290 1-135-834-91 CERAMIC CHIP 2.2uF 6.3V
C332 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C333 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C334 1-100-539-91 TANTAL. CHIP 47uF 20% 6.3V
C335 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C336 1-164-882-11 CERAMIC CHIP 220PF 5% 16V
C337 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C338 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C339 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C340 1-115-156-11 CERAMIC CHIP 1uF 10V
C341 1-135-337-11 TANTAL. CHIP 1uF 20% 6.3V
C342 1-135-337-11 TANTAL. CHIP 1uF 20% 6.3V
C352 1-135-151-21 TANTAL. CHIP 4.7uF 20% 4V
C354 1-135-151-21 TANTAL. CHIP 4.7uF 20% 4V
C355 1-100-539-91 TANTAL. CHIP 47uF 20% 6.3V
C356 1-110-569-21 TANTAL. CHIP 47uF 20% 4V
C357 1-115-156-11 CERAMIC CHIP 1uF 10V
MAIN
Ver 1.1
To Next Page
