2-7. REC/PB/ERASE HEAD (HRPE301), BELT (AR), CAPSTAN/REEL MOTOR (M601)
Attaching belt (AR)
3
belt (AR)
4
two screws (M1.4)
1
two screws (M1.4)
5
M601 (CAPSTAN/REEL motor)
2
HRPE301 (REC/PB/ERASE head)
