4
WM-GX410
2-3. MAIN BOARD
cabinet (center)
MAIN board
8
joint cover
4
two screws
5
screw
6
plate connector (L)
2
remove nine soldering
3
two screws (M1.4 toothed lock)
1
flexible board
(CN305)
7
2-4. MECHANISM DECK (MT-WMFX410-175)
2
three screws (IB lock)
5
hand strap
4
plate, connector (R
)
3
screw
mechanism deck (MT-WMGX410-175)
6
1
