Sony WM-GX410 Service Manual

29
WM-GX410
Ref. No. Part No. Description Remarks Ref. No. Part No. Description RemarksRef. No. Part No. Description Remarks
R315 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R316 1-216-805-11 METAL CHIP 47 5% 1/10W
R317 1-218-969-11 RES-CHIP 22K 5% 1/16W
R318 1-218-969-11 RES-CHIP 22K 5% 1/16W
R319 1-218-985-11 RES-CHIP 470K 5% 1/16W
R320 1-218-973-11 RES-CHIP 47K 5% 1/16W
R321 1-218-985-11 RES-CHIP 470K 5% 1/16W
R322 1-218-981-11 RES-CHIP 220K 5% 1/16W
R323 1-218-953-11 RES-CHIP 1K 5% 1/16W
(AEP)
R324 1-218-933-11 RES-CHIP 22 5% 1/16W
(EXCEPT AEP)
R324 1-218-949-11 RES-CHIP 470 5% 1/16W
(AEP)
R325 1-218-953-11 RES-CHIP 1K 5% 1/16W
(AEP)
R326 1-218-933-11 RES-CHIP 22 5% 1/16W
(EXCEPT AEP)
R326 1-218-949-11 RES-CHIP 470 5% 1/16W
(AEP)
R330 1-216-857-11 METAL CHIP 1M 5% 1/10W
R335 1-218-937-11 RES-CHIP 47 5% 1/16W
R336 1-208-635-11 METAL CHIP 10 0.5% 1/16W
R337 1-218-965-11 RES-CHIP 10K 5% 1/16W
R338 1-218-953-11 RES-CHIP 1K 5% 1/16W
R339 1-218-973-11 RES-CHIP 47K 5% 1/16W
R340 1-216-821-11 METAL CHIP 1K 5% 1/10W
R341 1-218-973-11 RES-CHIP 47K 5% 1/16W
R342 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R344 1-218-990-11 SHORT CHIP 0
R352 1-218-953-11 RES-CHIP 1K 5% 1/16W
R353 1-218-965-11 RES-CHIP 10K 5% 1/16W
R354 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R356 1-216-833-11 METAL CHIP 10K 5% 1/10W
R357 1-216-841-11 METAL CHIP 47K 5% 1/10W
R358 1-218-953-11 RES-CHIP 1K 5% 1/16W
R359 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R360 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R378 1-218-953-11 RES-CHIP 1K 5% 1/16W
R401 1-218-965-11 RES-CHIP 10K 5% 1/16W
R402 1-218-977-11 RES-CHIP 100K 5% 1/16W
R403 1-218-965-11 RES-CHIP 10K 5% 1/16W
R404 1-218-977-11 RES-CHIP 100K 5% 1/16W
R406 1-218-981-11 RES-CHIP 220K 5% 1/16W
R408 1-218-981-11 RES-CHIP 220K 5% 1/16W
R409 1-218-989-11 RES-CHIP 1M 5% 1/16W
R410 1-216-857-11 METAL CHIP 1M 5% 1/10W
R413 1-218-973-11 RES-CHIP 47K 5% 1/16W
R415 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R416 1-218-969-11 RES-CHIP 22K 5% 1/16W
R417 1-218-969-11 RES-CHIP 22K 5% 1/16W
R418 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R421 1-216-857-11 METAL CHIP 1M 5% 1/10W
R422 1-218-989-11 RES-CHIP 1M 5% 1/16W
R423 1-218-965-11 RES-CHIP 10K 5% 1/16W
R424 1-218-989-11 RES-CHIP 1M 5% 1/16W
R425 1-218-989-11 RES-CHIP 1M 5% 1/16W
R426 1-218-977-11 RES-CHIP 100K 5% 1/16W
R427 1-218-989-11 RES-CHIP 1M 5% 1/16W
R428 1-218-977-11 RES-CHIP 100K 5% 1/16W
R430 1-218-977-11 RES-CHIP 100K 5% 1/16W
R432 1-218-989-11 RES-CHIP 1M 5% 1/16W
R433 1-218-953-11 RES-CHIP 1K 5% 1/16W
R434 1-218-953-11 RES-CHIP 1K 5% 1/16W
R435 1-218-977-11 RES-CHIP 100K 5% 1/16W
R436 1-216-849-11 METAL CHIP 220K 5% 1/10W
R437 1-218-965-11 RES-CHIP 10K 5% 1/16W
R438 1-216-833-11 METAL CHIP 10K 5% 1/10W
R440 1-218-990-11 SHORT CHIP 0
R441 1-218-977-11 RES-CHIP 100K 5% 1/16W
R446 1-218-973-11 RES-CHIP 47K 5% 1/16W
R447 1-218-973-11 RES-CHIP 47K 5% 1/16W
R502 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R503 1-216-837-11 METAL CHIP 22K 5% 1/10W
R504 1-218-977-11 RES-CHIP 100K 5% 1/16W
R505 1-218-981-11 RES-CHIP 220K 5% 1/16W
R507 1-216-841-11 METAL CHIP 47K 5% 1/10W
R601 1-216-821-11 METAL CHIP 1K 5% 1/10W
R602 1-218-989-11 RES-CHIP 1M 5% 1/16W
R603 1-218-989-11 RES-CHIP 1M 5% 1/16W
R604 1-216-857-11 METAL CHIP 1M 5% 1/10W
R605 1-216-821-11 METAL CHIP 1K 5% 1/10W
R606 1-216-864-11 SHORT CHIP 0
R607 1-218-977-11 RES-CHIP 100K 5% 1/16W
R608 1-218-990-11 SHORT CHIP 0
R609 1-218-965-11 RES-CHIP 10K 5% 1/16W
R610 1-218-973-11 RES-CHIP 47K 5% 1/16W
R611 1-218-941-81 RES-CHIP 100 5% 1/16W
R612 1-218-973-11 RES-CHIP 47K 5% 1/16W
R613 1-218-941-81 RES-CHIP 100 5% 1/16W
R614 1-218-965-11 RES-CHIP 10K 5% 1/16W
R615 1-216-837-11 METAL CHIP 22K 5% 1/10W
R744 1-218-949-11 RES-CHIP 470 5% 1/16W
R764 1-218-945-11 RES-CHIP 220 5% 1/16W
R903 1-218-953-11 RES-CHIP 1K 5% 1/16W
R904 1-218-945-11 RES-CHIP 220 5% 1/16W
R905 1-218-945-11 RES-CHIP 220 5% 1/16W
R907 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R908 1-218-953-11 RES-CHIP 1K 5% 1/16W
(CND, 5E)
R909 1-218-953-11 RES-CHIP 1K 5% 1/16W
R912 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R920 1-218-953-11 RES-CHIP 1K 5% 1/16W
(CND, 5E)
R933 1-218-953-11 RES-CHIP 1K 5% 1/16W
< VARIABLE RESISTOR >
RV1 1-223-258-11 RES, ADJ CERMET 4.7K (FM VCO)
RV2 1-223-998-21 RES, CARBON ADJ VAR 100K (AM IF)
RV301 1-227-319-21 RES, VAR, CARBON 10K (VOLw)
RV601 1-223-258-11 RES, ADJ CERMET 4.7K
(TAPE SPEED 2.4cm/s)
RV602 1-223-258-11 RES, ADJ CERMET 4.7K
(TAPE SPEED 4.8cm/s)
MAIN
Ver 1.1
