SoundCraft COMPACT 4 - Typical Specifications; Technical Performance Data

37
USER GUIDEUSER GUIDE
USER GUIDEUSER GUIDE
USER GUIDE
TYPICAL SPECIFICATYPICAL SPECIFICA
TYPICAL SPECIFICATYPICAL SPECIFICA
TYPICAL SPECIFICA
TIONSTIONS
TIONSTIONS
TIONS
Noise (22Hz-22kHz measurement bandwidth)Noise (22Hz-22kHz measurement bandwidth)
Noise (22Hz-22kHz measurement bandwidth)Noise (22Hz-22kHz measurement bandwidth)
Noise (22Hz-22kHz measurement bandwidth)
Mic EIN @ max gain, 150 ohm source impedance ..........................................................................-128dBu
Mix @ unity, faders down ................................................................................................................<-85dBu
Crosstalk (typ. @ 1kHz)Crosstalk (typ. @ 1kHz)
Crosstalk (typ. @ 1kHz)Crosstalk (typ. @ 1kHz)
Crosstalk (typ. @ 1kHz)
Fader cut-off (rel +10 mark) ............................................................................................................. >80dB
Frequency responseFrequency response
Frequency responseFrequency response
Frequency response
Mic/Line input to any output ................................................................................. +/- 0.5dB 20Hz – 20kHz
THD+NoiseTHD+Noise
THD+NoiseTHD+Noise
THD+Noise
Mic gain 30dB
Mix out, fader max @ 1kHz ........................................................................................................... <0.007 %
Input & output ImpedancesInput & output Impedances
Input & output ImpedancesInput & output Impedances
Input & output Impedances
Mic input ............................................................................................................................................. 2kΩ
Line input ........................................................................................................................................ >10kΩ
Hi-Z input ...................................................................................................................................... >300kΩ
Stereo input ....................................................................................................................................... 47kΩ
Outputs ............................................................................................................................................... 75Ω
Input & output levelsInput & output levels
Input & output levelsInput & output levels
Input & output levels
Mic input max level ......................................................................................................................... +16dBu
Line input max level ........................................................................................................................ +30dBu
Stereo input max level ..................................................................................................................... +20dBu
Mix output max level ....................................................................................................................... +20dBu
Headphones (@ 200Ω) .................................................................................................................. 300mW
EQEQ
EQEQ
EQ
EQ Bands +/- 12dB
Lo ....................................................................................................................................................... 60Hz
Mid .................................................................................................................................................. 600Hz
Hi ......................................................................................................................................................12kHz
WeightWeight
WeightWeight
Weight
COMPACT4 ....................................................................................................................... 1.75 kg (3.85lb)
COMPACT10 ...................................................................................................................... 2.75kg (6.05lb)
AVERAGE POWER CONSUMPTION (QUIESCENT)AVERAGE POWER CONSUMPTION (QUIESCENT)
AVERAGE POWER CONSUMPTION (QUIESCENT)AVERAGE POWER CONSUMPTION (QUIESCENT)
AVERAGE POWER CONSUMPTION (QUIESCENT)
COMPACT4 ...................................................................................................................................... 8 Watts
COMPACT10 ................................................................................................................................. 14 Watts
MIN / MAX OPERAMIN / MAX OPERA
MIN / MAX OPERAMIN / MAX OPERA
MIN / MAX OPERA
TING TEMPERATING TEMPERA
TING TEMPERATING TEMPERA
TING TEMPERA
TURE (E SERIES FTURE (E SERIES F
TURE (E SERIES FTURE (E SERIES F
TURE (E SERIES F
AMILAMIL
AMILAMIL
AMIL
Y)Y)
Y)Y)
Y)
Centigrade / Farenheit .................................................................................... 0°C - 50°C / 32°F - 122°F
