SoundCraft Signature 22MTK User Manual

16, 22, 22MTK User Manual
4.3: FX RETURN
CONSOLE ROUTING > FX RETURN
4.3: FX RETURN ROUTING
An FX Return channel is a special stereo input channel is fed from the output of the internal FX
processor.
An FX Return channel can contribute to any Aux bus (EXCEPT its own source), and to the Master
and Group busses - as per mono and stereo input channels. Signature 22 and 22MTK consoles have
two FX Return channels as those consoles have two internal FX processors.

SoundCraft Signature 22MTK Specifications

General

Channels	22
Lexicon Effects	Yes
dbx Limiters	Yes, on input channels
Ghost Preamps	Yes
Faders	100mm
Power Supply	Internal
Type	Analog mixer
Phantom Power	Yes
Inputs - Line	22
Computer Connectivity	USB
Aux Sends	5
Inputs - Mic Preamps	16 x XLR
Inputs - Other	2 x RCA
Outputs - Main	2 x XLR, 2 x 1/4"
Outputs - Other	6 x Aux Send, 1 x Headphone
Weight	11.34 kg
USB Interface	24-in/22-out USB audio interface
