SoundCraft Signature 22MTK User Manual

16, 22, 22MTK User Manual
1.0.1: SIGNATURE LEGACY
SIGNATURE LEGACY
1.0.1: SIGNATURE LEGACY
The Signature Series consoles bring musicality, creativity, and technical excellence together, thanks
not only to new technology and ideas, but also to a 40-year legacy of producing outstanding perfor-
mance tools. This console incorporate classic analogue designs, approved by Engineers.
Ghost® pre-amps
The Soundcraft Ghost console’s ProMic
mic pre-amp is known for it’s ultra-low
noise and high headroom, making high
gain settings possible, without
compromising signal integrity.
Sapphyre British EQ
The Soundcraft Sapphyre console Asym-
metric EQ makes both creative and func-
tional tonal shaping of your signal simple
and intuitive. The EQ behaves differently
in cut and boost, making tonal adjust-
ments musical, and focusing cuts where
they are needed. See section 1.0.2 for
more detail.
GB Routing
The GB Console legacy is in Signature’s
signal routing. There is pre/post switching
forallauxbusses,plusexibleroutingand
dedicated outputs for sub-groups.
See section 4 for more detail.

SoundCraft Signature 22MTK Specifications

General

Channels	22
Lexicon Effects	Yes
dbx Limiters	Yes, on input channels
Ghost Preamps	Yes
Faders	100mm
Power Supply	Internal
Type	Analog mixer
Phantom Power	Yes
Inputs - Line	22
Computer Connectivity	USB
Aux Sends	5
Inputs - Mic Preamps	16 x XLR
Inputs - Other	2 x RCA
Outputs - Main	2 x XLR, 2 x 1/4"
Outputs - Other	6 x Aux Send, 1 x Headphone
Weight	11.34 kg
USB Interface	24-in/22-out USB audio interface
