SoundCraft Signature 22MTK User Manual

16, 22, 22MTK User Manual
4.4: AUX MASTER
CONSOLE ROUTING > AUX MASTER
4.4: AUX MASTER ROUTING
Aux busses sent directly out of the corresponding Aux outputs, and are globally switchable between
pre- and post-fade sources. That is, an Aux mix that is taken ‘pre-fade’ (before the input channel
fader) is not affected by the input channel fader levels. An Aux mix taken ‘post-fade’ (after the input
channel fader) will be based on the fader levels of the contributing input channels.
The Playback Channel (highest-numbered stereo input) Aux 1 and 2 sends can be individually
switched post-fader. This is useful where, for example, the Aux 1/2 outputs are being used for pre-
fade stage monitors. By switching the ‘playback’ (incidental of interval music for example) to post-fad-
er, musicians will be able to hear the playback music when it is faded up, and still allow the console
operator to hear the channel on PFL without it being heard in a monitor.
Aux Masters can contribute to the Solo bus (AFL). See section 6 for more details.

SoundCraft Signature 22MTK Specifications

General

Channels	22
Lexicon Effects	Yes
dbx Limiters	Yes, on input channels
Ghost Preamps	Yes
Faders	100mm
Power Supply	Internal
Type	Analog mixer
Phantom Power	Yes
Inputs - Line	22
Computer Connectivity	USB
Aux Sends	5
Inputs - Mic Preamps	16 x XLR
Inputs - Other	2 x RCA
Outputs - Main	2 x XLR, 2 x 1/4"
Outputs - Other	6 x Aux Send, 1 x Headphone
Weight	11.34 kg
USB Interface	24-in/22-out USB audio interface
