SoundCraft Signature 22MTK User Manual

16, 22, 22MTK User Manual
5.0: CHANNEL CONTROLS
CHANNEL CONTROLS
5.0: CHANNEL CONTROL
There are three types of Signature console input channels: Mono Input, Stereo Input, and FX Return.
The output channel types are the Auxiliary (Aux) Master Outputs, the Master Stereo Outputs, and the
Group (GRP) Master Outputs.

SoundCraft Signature 22MTK Specifications

General

Channels	22
Lexicon Effects	Yes
dbx Limiters	Yes, on input channels
Ghost Preamps	Yes
Faders	100mm
Power Supply	Internal
Type	Analog mixer
Phantom Power	Yes
Inputs - Line	22
Computer Connectivity	USB
Aux Sends	5
Inputs - Mic Preamps	16 x XLR
Inputs - Other	2 x RCA
Outputs - Main	2 x XLR, 2 x 1/4"
Outputs - Other	6 x Aux Send, 1 x Headphone
Weight	11.34 kg
USB Interface	24-in/22-out USB audio interface
