SoundCraft Signature 22MTK User Manual

16, 22, 22MTK User Manual
7.2: SIGNATURE 22MTK USB
USB > SIGNATURE 22MTK
7.2: SIGNATURE 22MTK USB
USB I/O
A USB Standard-B Plug for USB data connection
The USB connector above the highest-numbered stereo channel is for audio data connection. Please note, the
USB Standard-A plug next to the PHANTOM POWER switch is for powering USB devices only (charging devices,
USB-powered lamps, and so on).
USB RTN
Press to use the USB return-path for this channel
The USB audio channel corresponding to the input channel number will be used instead of the normal channel
input. The red LED indicator on the button will light to show that the function is active.
NOTE: The analoue input to an input channel will ALWAYS be SENT via the corresponding USB audio channel, so
you can use a USB SEND > DAW > USB RTN path to insert DAW-based plug-ins into the mixer’s channel path.

SoundCraft Signature 22MTK Specifications

General

Channels	22
Lexicon Effects	Yes
dbx Limiters	Yes, on input channels
Ghost Preamps	Yes
Faders	100mm
Power Supply	Internal
Type	Analog mixer
Phantom Power	Yes
Inputs - Line	22
Computer Connectivity	USB
Aux Sends	5
Inputs - Mic Preamps	16 x XLR
Inputs - Other	2 x RCA
Outputs - Main	2 x XLR, 2 x 1/4"
Outputs - Other	6 x Aux Send, 1 x Headphone
Weight	11.34 kg
USB Interface	24-in/22-out USB audio interface
