Page #27 background imageLoading...
Page #27 background image
3.2.1: KEYBOARD CONTROL
SOFTWARE > KEYBOARD CONTROL
3.2.1: KEYBOARD CONTROL
For users mixing with a device that has a keyboard, please see below a set of easily accessible key com-
mands, making it quick and efcient to access the most used features on the mixer.
Ui12, Ui16 User Manual
[1] DASHBOARD
[2] MIX/GAIN
[3] EDIT
[4] AUX SENDS
[5] FX SENDS
[6] MEDIA
[7] SETTINGS
[8] SNAPSHOTS (Same as click in NAV Display)
[9] SLIDEOUT
[SPACEBAR] SLIDEOUT.
[Q] FX RETURNS
[W] SUB GROUPS
[E] AUX MASTERS
[A] MUTE ALL
[P] PRESETS
[F] MUTE FX
[M] MUTE
[S] SOLO
[C] CHANNEL POP UP MENU
[~] UNDO (last page viewed)
[Left arrow] Jump 1 channels to the left
[Right arrow] Jump 1 channels to the right
[Up arrow] Jump 8 channels to the left
[Down arrow] Jump 8 channels to the right
[TAB] Toggle through the tabs inside EQ, DYN, FX, AUX.
