SoundCraft Ui16 User Guide

CONTENTS
CONTENTS
CONTENTS
1.0 AN INTRODUCTION TO Ui
1.1: Safety
1.2: Warranty
 1.3:Specications
2.0: GETTING STARTED
2.1:SystemOverview
 2.2:HardwareI/O&Control
 2.3:InputChannelRouting
 2.4:GettingConnected
3.0: SOFTWARE CONTROL
3.0.1: Updates&Requirements
3.1: SoftwareNavigation
  3.1.1:Control/GestureSummary
3.2: TabletNavigation
  3.2.1:KeyboardControl
 3.3:TabletScreens
3.4: PhoneNavigation
3.5: PhoneScreens
4.0: MIXER CHANNELS
 4.1:InputGainPage
 4.2:InputMixPage
  4.2.1:InputSubMenu
 4.3:AuxSends
  4.3.1:AuxMaster
 4.4:FXSends
 4.5:GroupMaster
 4.6:MasterChannel
5.0: CHANNEL EDIT
 5.1:DigiTech
 5.2:ParametricEQ
 5.3:GraphicEQ
5.3.1 AFS
2
-FeedbackElimination
 5.4:Dynamics
 5.5:Aux/FXSends
6.0: MIX FEATURES
 6.1:View&MuteGroups
 6.2:MoreMe
7.0: LEXICON FX EDIT
 7.1:Reverb
 7.2:Delay
 7.3:Chorus
8.0: SHOWS & SNAPSHOTS
9.0: MEDIA PLAYER & RECORDER
10.0: SETTINGS
 10.1:NetworkConguration
  10.1.1:HotspotSettings
  10.1.2:Wi-FiSettings
  10.1.3:LANSettings
For clarity, this manual uses section references rather than page numbers. In some instances, one section reference
may extend to several pages.
Ui12, Ui16 User Manual

SoundCraft Ui16 Specifications

General

Channels	16
Mic Preamps	8
USB Playback	Yes
Built-in Wi-Fi	Yes
XLR Inputs	8
Aux Sends	4
Phantom Power	Yes
Sampling Rate	48 kHz
Bit Depth	24-bit
Ethernet Port	1
Remote Control	Remote control via HTML5-compatible browser
RCA Inputs	2
Control	Control via any device with a web browser
Wi-Fi	Built-in Wi-Fi
Microphone Preamps	8
USB Audio Interface	2-channel recording/playback
Monitor Outputs	2
Aux Outputs	4
Power Supply	Internal
USB	USB playback and recording
Dimensions	177 x 482 x 89 mm
Weight	3.9kg (8.6 lbs)
